| Item | Hazardous Location Motor |
|---|---|
| Ac/dc | DC |
| Ambient Temp. | 40°C |
| Armature Amps | 4.9A |
| Armature Inertia | 19.385 lbs.-sq. ft. |
| Armature Voltage | 90V |
| Base Indicator | Rigid |
| Base Rpm | 1750 RPM |
| Base Type | Rigid Base |
| Brushes | 2/BP5125A01 |
| Class | Stock |
| Conduit Box Material | Steel |
| Conduit Box Position | F1 |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Enclosure Design | TEFC |
| Enclosure Type | Explosion Proof Fan Cooled |
| Field Amps | 0.55/1.1A |
| Field Voltage | 50/100V |
| Field Winding Type | Shunt |
| Frame | 182CZ |
| Frame Material | Steel |
| Frame Size | 182CZ |
| Hazardous Location Class | 1D/2F, G |
|---|---|
| Hazardous Location Division | Division 1 |
| Hp | 1/2 hp |
| Insulation Class | Class A |
| Motor Type | Shunt Wound |
| Multiplier | L1 |
| Nameplate Rpm | 1750 RPM |
| Nema/iec | NEMA |
| No. Of Poles | 2 |
| Output | 1/3 hp |
| Overall Length | 18.61" |
| Proprietary | No |
| Revision | AJ |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Temp. Code | T3B |
| Type | 3623D |
| Voltage | 90V |
| Xp Class And Group | Class I Group D/Class II Group F, G |
| Height (cm) | 42.54 |
|---|---|
| Length (cm) | 69.69 |
| Width (cm) | 46.52 |
| HS Code | 85015100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 45.9 |
