| Item | High Capacity Pleated Filter |
|---|---|
| Actual Depth | 3 3/4" |
| Actual Filter Size | 15 1/2" x 19 1/2" x 3 3/4" |
| Actual Height | 15 1/2" |
| Actual Width | 19 1/2" |
| Air Filter Capacity | High Capacity |
| Air Flow @ 300 Fpm | 667 CFM |
| Air Flow @ 500 Fpm | 1111 CFM |
| Common Applications | General Use |
| Filter Efficiency - Air Filters | 65% |
| Filter Frame Color | White |
| Filters Out | Auto Emission Particulates, Coal Dust, Humidifier Dust, Lead Dust, MERV 9-12 Legionella, Milled Flour, Nebulizer Droplets |
| Final Recommended Resistance | 1 in. wc |
| Frame | Yes |
| Frame Material | Chipboard |
| Frame Or Header Material | Beverage Board |
| Frame Type | Moisture Resistant Die Cut Chipboard |
| High Initial Resistance | 0.38 in. wc |
| High Velocity | 625 FPM |
| Initial Resistance @ 300 Fpm | 0.2 in. wc |
|---|---|
| Initial Resistance @ 500 Fpm | 0.33 in. wc |
| Material Properties | Moisture Resistant Die Cut |
| Max. Temp. | 180°F |
| Max. Velocity | 500 FPM |
| Media Area | 18 sq. ft. |
| Media Color | White |
| Media Material | Synthetic |
| Nominal Depth | 4" |
| Nominal Filter Size | 16" x 20" x 4" |
| Nominal Height | 16" |
| Nominal Width | 20" |
| Performance Rating (meets Or Exceeds) | MERV 11 |
| Pleats Per Linear Feet | 9 |
| Pleats Per Linear Foot | 16 |
| Style - Air Filters | Panel |
| Gasket Location | None |
| Gasket Material | None |
| Standards | UL 900 CLASSIFIED |
| Height (cm) | 60.96 |
|---|---|
| Length (cm) | 40.64 |
| Width (cm) | 50.8 |
| HS Code | 8421398090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.765 |
| Style | Model | Nominal Depth | Air Filter Capacity | Nominal Filter Size | Nominal Height | Nominal Width | Actual Height | High Velocity | Actual Filter Size | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 2DYD3 | 2" | High Capacity | 20" x 24" x 2" | 20" | 24" | 19 1/2" | 500 FPM | 19 1/2" x 23 1/2" x 1 3/4" | $19.15 | |
| A | 2DYD7 | 2" | High Capacity | 20" x 25" x 2" | 20" | - | 19 1/2" | 500 FPM | 19 1/2" x 24 1/2" x 1 3/4" | $18.64 | |
| B | 2DYE2 | 2" | High Capacity | 24" x 24" x 2" | 24" | 24" | 23 3/8" | 500 FPM | 23 3/8" x 23 3/8" x 1 3/4" | $19.46 | |
| B | 2DYE6 | 2" | - | 25" x 25" x 2" | - | - | 24 3/4" | 500 FPM | - | $20.66 | |
| C | 2DYE9 | 4" | High Capacity | 12" x 24" x 4" | - | - | 11 3/8" | 625 FPM | 11 3/8" x 23 3/8" x 3 3/4" | $25.04 | |
| D | 2DYF8 | 4" | High Capacity | 16" x 25" x 4" | 16" | 25" | 15 1/2" | 625 FPM | 15 1/2" x 24 1/2" x 3 3/4" | $37.01 | |
| D | 2DYG3 | 4" | High Capacity | 18" x 24" x 4" | 18" | - | 17.375" | 625 FPM | 17 3/8" x 23 3/8" x 3 3/4" | $33.59 |
