| Item | Coupling |
|---|---|
| Application | Potable Water |
| Barb Style | Standard |
| Basic Pipe Fitting Material | Metal |
| Basic Pipe Fitting Shape | Coupling |
| Body Material | Low Lead Brass |
| Connection Type | PEX |
| Fitting Material | Brass |
| Fitting Side A Connection Type | Barbed |
| Fitting Side A Tube Inner Diameter | 1" |
| Fitting Side B Connection Type | Barbed |
| Fitting Side B Tube Inner Diameter | 3/4" |
| Max. Pressure | 80 psi |
| Maximum Operating Pressure | 160 psi |
|---|---|
| Maximum Operating Temperature | 200°F |
| Minimum Operating Temperature | 33°F |
| Overall Length | 1 1/2" |
| Pex Size | 1" x 3/4" |
| Pipe Fitting Material | Low Lead Brass |
| Pipe Size | 1" x 3/4" |
| Resistance Properties | Corrosion Resistant, Freeze Damage Resistant, Mineral Buildup Resistant, Rust Resistant |
| Size | 1" x 3/4" |
| Specific Fitting Shape | Straight Reducing Connector |
| Specific Pipe Fitting Shape | Coupling |
| Temp. Range | +33°F to +200°F |
| Standards | ASTM F1807, ASTM F877, CSA B137.5, NSF/ANSI 14, NSF/ANSI 372, NSF/ANSI 61 |
| Height (cm) | 3.81 |
|---|---|
| Length (cm) | 3.81 |
| Width (cm) | 2.54 |
| HS Code | 7412200045 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 0.036 |
| Style | Model | Specific Fitting Shape | Pipe Size | Fitting Material | Overall Length | Pex Size | Fitting Side A Tube Inner Diameter | Size | Connection Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | QQC65GX | Straight Reducing Connector | 1 1/4" x 1" | Brass | 2 7/32" | 1 1/4" x 1" | 1 1/4" | 1 1/4" x 1" | PEX | $22.44 | |
| A | QQC66GX | Straight Connector | 1 1/4" | Brass | 2 9/16" | 1 1/4" | 1 1/4" | 1 1/4" x 1 1/4" | PEX | $24.21 | |
| A | QQC76GX | Straight Reducing Connector | 1 1/2" x 1 1/4" | Brass | 2 9/16" | 1 1/2" x 1 1/4" | 1 1/2" | 1 1/2" x 1 1/4" | PEX | $39.06 | |
| A | QQC77GX | Coupling | 1 1/2" | Brass | - | 1 1/2" | - | - | PEX | $39.29 | |
| A | QQC87GX | Straight Reducing Connector | 2" x 1 1/2" | Brass | 3 1/32" | 2" x 1 1/2" | 2" | 2" x 1 1/2" | PEX | $64.99 | |
| A | QQC88GX | Straight Connector | 2" | Brass | 3 3/8" | 2" | 2" | 2" x 2" | PEX | $63.34 | |
| A | QQC22GX | Straight Connector | 3/8" | Brass | 1 3/8" | 3/8" | 3/8" | 3/8" x 3/8" | PEX | $3.66 |
