| Item | Hazardous Location Motor |
|---|---|
| Ambient Temp. | 40°C |
| Cc Number | CC029A |
| Conduit Box Location | Exterior |
| Duty Cycle | Continuous |
| Efficiency | 50% |
| Efficiency @ 100% | 86.5% |
| Efficiency Group | Premium |
| Enclosure | IC411 |
| Enclosure Type | Tefc |
| Flange | Without |
| Frame | 145T |
| Frame Material | Cast Iron |
| Frame Size | 145T |
| Frequency | 50/60 Hz |
| Full Load Amps | 2.72/5.44-6.02A |
| Green Certification Or Other Recognition | NEMA Premium Rated |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| Hazardous Location Class | 1 C, D / 2 F, G |
| Hazardous Location Division | Division 1 |
| Hp | 2 hp |
| Hz | 60 Hz |
| Ins. Class | Class F |
| Insulation Class | Class F |
| Length Less Shaft | 11 1/2" |
| Manufacturers Warranty Length | 3 yrs. |
| Max. Ambient Temp. | 104°F |
| Motor Application | Hazardous Location |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Frame Material | Cast Iron |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
|---|---|
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | T Stat |
| Motor Type | Three Phase |
| Mounting | F-1 |
| Mounting Type | Foot Mounted |
| Nameplate Rpm | 1750 RPM |
| Nema Design | B |
| No Load Amps | 1.5/3A |
| No. Of Speeds | 1 |
| Noise | 51 dBA |
| Nominal Efficiency | 86.5% |
| Number Of Poles | 4 |
| Output Rating | 2 hp |
| Overall Length | 13 3/4" |
| Phase | 3 |
| Power Factor | 75% |
| Power Factor_100% | 0.8 |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2 1/4" |
| Synchronous Speed | 1800 RPM |
| Temp. Code | T4 |
| Terminal Box | Left Position |
| Torque | 5.92 lbs.-ft. |
| Usable @ 200v | No |
| Usable @ 208v | Yes |
| Voltage | 230/460/380V |
| Warranty | 3 yrs. |
| Standards | CSA CERTIFIED (LR50962), UL LISTED (E87848) |
| Height (cm) | 27.18 |
|---|---|
| Length (cm) | 34.92 |
| Width (cm) | 34.8 |
| HS Code | 8501524000 |
|---|---|
| Country Of Origin | BR |
| Weight (kg) | 31.95 |
| Style | Model | Voltage | Frame | Nameplate Rpm | Hp | Motor Application | Hazardous Location Class | Synchronous Speed | Flange | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 00118XT3E143T | 230/460/380V | 143T | 1765 RPM | 1 hp | Hazardous Location | 1 C, D / 2 F, G | 1800 RPM | Without | $1,328.39 | |
| A | 00156XT3E143T | 230/460/380V | 143T | 3500 RPM | 1 1/2 hp | Hazardous Location | 1 C, D / 2 F, G | 3600 RPM | Without | $1,342.32 | |
| A | 00158XT3E145T | 230/460/380V | 145T | 1760 RPM | 1 1/2 hp | Hazardous Location | 1 C, D / 2 F, G | 1800 RPM | Without | $1,377.72 | |
| A | 00152XT3E182T | 230/460/380V | 182T | 1165 RPM | 1 1/2 hp | Hazardous Location | 1 C, D / 2 F, G | 1200 RPM | Without | $1,724.09 | |
| A | 00236XT3E145T | 230/460/380V | 145T | 3480 RPM | 2 hp | Hazardous Location | 1 C, D / 2 F, G | 3600 RPM | Without | $1,375.76 | |
| A | 00212XT3E184T | 230/460/380V | 184T | 1165 RPM | 2 hp | Hazardous Location | 1 C, D / 2 F, G | 1200 RPM | Without | $1,736.55 | |
| A | 00336XT3E182T | 230/460/380V | 182T | 3515 RPM | 3 hp | Hazardous Location | 1 C, D / 2 F, G | 3600 RPM | Without | $1,718.55 |
