| Item | Jobber Drill Bit |
|---|---|
| Coolant Fed | Non Coolant Through |
| Cutting Direction | Right |
| Decimal Equivalent | 0.1181 |
| Depthdia. Ratio | 3xd |
| Dimension Type | Metric |
| Drill Bit Point Angle | 150° |
| Drill Bit Point Type | Conventional Point |
| Drill Bit Size | 3 mm |
| Drill Diameter Tolerance | H7 |
| Drill Length Class | Screw Machine Length |
| Drill Point Length | 0.402 mm |
| Finish - Machining | Bright (Uncoated) |
| Flute Length | 23.5 mm |
| Flute Type | Spiral |
| Grade | Grade A |
| Material | Solid Carbide |
| Material - Machining | Carbide |
|---|---|
| Material Grade - Machining | Grade A |
| Measurement System | Metric |
| Number Of Flutes | 3 |
| Overall Length | 46 mm |
| Point Angle | 150° |
| Primary Material Application | Aluminum, Brass, Bronze, Copper, Hardened Steel, Nickel, Steel, Titanium |
| Primary Material Application Iso Code | H, N, P |
| Shank Dia. | 3 mm |
| Shank Length | 24 mm |
| Shank Type - Machining | Straight |
| Sheeter Drill | No |
| Standards | Tp-Norm 4 |
| Cutting Edge Dia. | 0.118" |
| Cutting Edge Length | 0.669" |
| Length | 1.811" |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 4.6 |
| Width (cm) | 2.54 |
| HS Code | 8209000030 |
|---|---|
| Country Of Origin | FR |
| Weight (kg) | 0.0045 |
| Style | Model | Flute Length | Shank Dia. | Overall Length | Drill Bit Size | Decimal Equivalent | Drill Bit Point Type | Dimension Type | Grade | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | A1166-7.3 | 48.65 mm | 7.3 mm | 74 mm | 7.3 mm | 0.2874 | Conventional Point | Metric | Grade A | $152.87 | |
| A | A1166-7.4 | 48.7 mm | 7.4 mm | 74 mm | 7.4 mm | 0.2913 | Conventional Point | Metric | Grade A | $152.87 | |
| A | A1166-7.5 | 48.76 mm | 7.5 mm | 74 mm | 7.5 mm | 0.2953 | Conventional Point | Metric | Grade A | $136.64 | |
| A | A1166-3.1 | 25.55 mm | 3.1 mm | 49 mm | 3.1 mm | 0.122 | Conventional Point | Metric | Grade A | $62.40 | |
| A | A1166-3.2 | 25.6 mm | 3.2 mm | 49 mm | 3.2 mm | 0.126 | Conventional Point | Metric | Grade A | $62.40 | |
| A | A1166-3.3 | 25.65 mm | 3.3 mm | 49 mm | 3.3 mm | 0.1299 | Conventional Point | Metric | Grade A | $62.40 | |
| A | A1166-3.4 | 28.7 mm | 3.4 mm | 52 mm | 3.4 mm | 0.1339 | Conventional Point | Metric | Grade A | $62.40 |
