| Item | Gate Valve |
|---|---|
| Ansi Flange Class | Not Applicable |
| Body Material | PVC |
| Bonnet Material | PVC |
| Bonnet Style | Welded |
| Class | Class 125 |
| Connection Gender - Side 1 | Female |
| Connection Gender Side 2 | Female |
| Connection Size - Side 1 | 8" |
| Connection Size - Side 2 | 8" |
| Connection Type | Slip x Slip |
| Connection Type - Side 1 | Slip |
| Connection Type - Side 2 | Slip |
| For Media | Water |
| Handle Height | 16 21/25" |
| Handle Length | Not Applicable |
| Handle Material | Plastic |
| Handle Type | Lever |
| Inlet To Outlet Length | 13 3/4" |
| Max. Fluid Temp. | 167°F |
| Max. Pressure (cwp) | 10 psi |
| Max. Pressure (steam) | 10 psi |
|---|---|
| Max. Water Pressure | 10 psi |
| Media Temp. Range | 167°F |
| Min. Operating Temp. | Not Applicable |
| Nominal Valve Size | 8" |
| Number Of Flange Bolt Holes | 12 |
| Operating Temperature - Maximum | 167°F |
| Overall Length | 13.75" |
| Pipe Size | 8" |
| Seal Material | TPE |
| Seat Material | Stainless Steel |
| Stem Grade | Grade 304 |
| Stem Material | 304 Stainless Steel |
| Stem Type | Rising |
| Top Of Handle To Inlet Center | 16.844" |
| Valve Class | Class 125 |
| Valve Stem Type | Rising |
| Wedge Material | 304 Stainless Steel |
| Wedge Style | Solid |
| Standards | MSS-SP-70 |
| Height (cm) | 38.86 |
|---|---|
| Length (cm) | 60.71 |
| Width (cm) | 29.46 |
| HS Code | 8481805090 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 7.9425 |
| Style | Model | Pipe Size | Seat Material | Max. Water Pressure | Top Of Handle To Inlet Center | Inlet To Outlet Length | Handle Material | Stem Material | Wedge Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 4201GR | 2" | Stainless Steel | 40 psi | 5 1/2" | 3 1/2" | Metal | Stainless Steel | - | $67.53 | |
| B | 4301GR | 3" | Stainless Steel | 30 psi | 7.156" | 4 1/2" | Metal | Stainless Steel | Stainless Steel | $75.19 | |
| C | 6401GR | 4" | Stainless Steel | 20 psi | 9 15/16" | 5.187" | Metal | Stainless Steel | Stainless Steel | $201.33 | |
| D | 6601 | 6" | Stainless Steel | 10 psi | 16.844" | 11 1/8" | Metal | 304 Stainless Steel | 304 Stainless Steel | $737.95 | |
| A | 6201GR | 2" | Polypropylene | 40 psi | 5 1/2" | 3 1/2" | Plastic | Stainless Steel | Polypropylene | $43.03 | |
| D | 6910 | 10" | Stainless Steel | 10 psi | 23 3/4" | 13 1/8" | Metal | 304 Stainless Steel | 304 Stainless Steel | $1,616.18 | |
| D | 6912 | 12" | Stainless Steel | 10 psi | 23 3/4" | 15 1/8" | Metal | 304 Stainless Steel | 304 Stainless Steel | $1,675.31 |
