| Item | Silent Check Valve |
|---|---|
| 3-a Compliance | Not Rated |
| Ansi Flange Class | Class 125 |
| Application - Valves | General Purpose |
| Body Material | Ductile Iron |
| Check Mechanism | Double Disc |
| Connection Size - Side 1 | 12" |
| Connection Size - Side 2 | 12" |
| Connection Type | Class 125 Flange |
| Connection Type - Side 1 | Flange |
| Connection Type - Side 2 | Flange |
| Cracking Pressure | 0.5 psi |
| Flow Design | Single |
| Flow Rate | 3500 GPM |
| For Media | Water |
| Full Flow - Valves | No |
| Grade | Grade 316 |
| Length | 19" |
| Max. Flow Rate | 3500 GPM |
| Max. Pressure (cwp) | 200 psi |
| Max. Pressure (steam) | Not Rated |
| Max. Steam Pressure - Valves | Not Rated |
| Max. Temp. | 150°F |
| Max. Water Pressure | 200 psi |
| Media Temp. Range | 33°F to 200°F |
|---|---|
| Media Temperature Range | 33°F to 200°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Mounting Position | Horizontal/Vertical |
| Nsf Certifications For Food And Drinking Water | NSF 61 |
| Operating Temperature - Maximum | 200°F |
| Operating Temperature - Minimum | 33°F |
| Overall Length | 14.25" |
| Pipe Or Tube Size | 12" |
| Pipe Or Tube Size - Check Valves | 12" |
| Seal Material | Bronze |
| Seal Material - Check Valves | Metal |
| Seat Material | Bronze |
| Seat Material - Check Valves | Bronze |
| Silent Check | Silent |
| Size | 12" |
| Spring Material | Stainless Steel |
| Vacuum Service Rating | Not Rated |
| Valve Body Style | Inline |
| Valve Series | 1800 Series |
| Width | 20" |
| Standards | ASME B16.34, ISO 9001, MSS SP-126, NSF/ANSI 372 |
| Height (cm) | 46.99 |
|---|---|
| Length (cm) | 107.95 |
| Width (cm) | 107.95 |
| HS Code | 8481302010 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 157.5 |
| Style | Model | Max. Flow Rate | Flow Rate | Body Material | Connection Type | Pipe Size | Max. Temp. | Seat Material | Cracking Pressure | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1825A-DSY | 150 GPM | 88 GPM | Ductile Iron | Class 125 Flange | 2 1/2" | 150°F | Bronze | 0.5 psi | $1,164.36 | |
| A | 1803A-DSY | 225 GPM | 130 GPM | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $1,342.90 | |
| A | 1804A-DSY | 400 GPM | 228 GPM | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $1,698.19 | |
| A | 1805A-DSY | 625 GPM | 350 GPM | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $2,003.11 | |
| A | 1806A-DSY | 900 GPM | 520 GPM | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $2,635.14 | |
| A | 1808A-DSY | 1600 GPM | 900 GPM | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $3,949.09 | |
| A | 1810A-DSY | 2500 GPM | - | Ductile Iron | Class 125 Flange | - | 150°F | Bronze | 0.5 psi | $5,940.36 |
