| Item | Thrust Bearing |
|---|---|
| Bearing Design | NTA/TC |
| Bearing Industry Number | 1828 |
| Bore Dia. | 28.6 mm |
| Bore Diameter | 1 1/8" |
| Cage Material | Alloy Steel |
| Compatible Washer | TRA-1828, TRB-1828, TRC-1828, TRD-1828 |
| Dynamic Axial Load Capacity | 3700 lbf. |
| Dynamic Load Capacity | 16100N |
| Height | 1.98 mm |
| Lubricant Material | Oil |
| Lubrication | Oil |
| Material | Steel |
| Max. Speed | 9300 RPM |
|---|---|
| Maximum Speed | 9000 RPM |
| Maximum Temperature | 250°F |
| Minimum Temperature | -5°F |
| Outside Dia. | 44.5 mm |
| Outside Diameter | 1 3/4" |
| Overall Width | 0.078" |
| Roller Material | Alloy Steel |
| Roller Material Grade | Grade 52100 |
| Static Axial Load Capacity | 16000 lbf. |
| Static Load Capacity | 68680N |
| Thrust Bearing Type | Thrust Needle Roller And Cage Assembly |
| Type | Needle Roller |
| Height (cm) | 0.2 |
|---|---|
| Length (cm) | 4.44 |
| Width (cm) | 4.44 |
| HS Code | 8482400000 |
|---|---|
| Weight (kg) | 0.027 |
| Style | Model | Bore Dia. | Dynamic Load Capacity | Max. Speed | Outside Dia. | Height | Cage Material | Static Load Capacity | Dynamic Axial Load Capacity | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | NTA1018 | 15.9 mm | 9440N | 14500 RPM | - | 1.98 mm | Alloy Steel | 29320N | 2200 lbf. | $8.37 | |
| A | NTA1220 | 19.1 mm | 10520N | 13500 RPM | 31.8 mm | 1.98 mm | Alloy Steel | 35200N | 2400 lbf. | $9.06 | |
| A | NTA1423 | 22.2 mm | 12960N | 11600 RPM | 36.5 mm | 1.98 mm | Alloy Steel | 477330N | 3000 lbf. | $8.56 | |
| A | NTA1625 | 25.4 mm | 13350N | 10600 RPM | 39.7 mm | 1.98 mm | Alloy Steel | 51940N | 3100 lbf. | $10.07 | |
| A | NTA2031 | 31.8 mm | 19450N | 8300 RPM | 49.2 mm | 1.98 mm | Alloy Steel | 90140N | 4500 lbf. | $9.16 | |
| A | NTA2233 | 34.9 mm | 20600N | 7700 RPM | 52.4 mm | 1.98 mm | Alloy Steel | 99590N | 4800 lbf. | $11.60 | |
| A | NTA2435 | 38.1 mm | 22410N | 7300 RPM | 55.6 mm | 1.98 mm | Alloy Steel | 113750N | 5200 lbf. | $11.74 |
