| Item | Double Disc Check Valve |
|---|---|
| Application - Valves | Process Piping |
| Body Material | Stainless Steel |
| Check Mechanism | Double Disc |
| Class | Class 600 |
| Connection Size - Side 1 | 2" |
| Connection Type | Wafer |
| Connection Type - Side 1 | Wafer |
| Connection Type - Side 2 | Wafer |
| Cracking Pressure | 0.3 psid |
| Disc Material | Cf8M Stainless Steel |
| Flow Design | Single |
| Flow Rate | 400 GPM |
| For Media | Process Piping |
| Full Flow - Valves | Yes |
| Includes Counterweight | No Counterweight |
| Length | 4 1/8" |
| Material | Stainless Steel |
| Max. Pressure (cwp) | 1480 psi |
| Max. Pressure (steam) | 1480 psi |
| Max. Temp. | 600°F |
| Media Temp. Range | 60°F to 600°F |
|---|---|
| Media Temperature Range | 60°F to 600°F |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Orientation - Check Valves | Horizontal, Vertical |
| Operating Temperature - Maximum | 600°F |
| Operating Temperature - Minimum | 60°F |
| Overall Height | 4 3/8" |
| Overall Length | 4.125" |
| Pipe Or Tube Size | 2" |
| Pipe Or Tube Size - Check Valves | 2" |
| Seal Material | CF8M Stainless Steel |
| Seal Material - Check Valves | Metal |
| Seat Material | Stainless Steel |
| Seat Material - Check Valves | Stainless Steel |
| Size | 2" |
| Spring Material | Nickel Alloy |
| Spring Material - Check Valves | Stainless Steel |
| Valve Body Style | Inline |
| Width | 2 3/25" |
| Standards | API 594, API 598 |
| Height (cm) | 17.78 |
|---|---|
| Length (cm) | 31.5 |
| Width (cm) | 13.72 |
| HS Code | 8481302090 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 3.0825 |
| Style | Model | Body Material | Pipe Size | Max. Temp. | Seat Material | Overall Height | Seal Material | Spring Material | Flow Rate | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 0200-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 4 1/8" | Buna N | 316 Stainless Steel | 400 GPM | $151.93 | |
| A | 0250-125WTIBB-T | Cast Iron | 2 1/2" | 250°F | Buna N | 4 7/8" | Buna N | 316 Stainless Steel | 500 GPM | $161.86 | |
| A | 0300-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 5 3/8" | Buna N | 316 Stainless Steel | 700 GPM | $209.27 | |
| A | 0400-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 6 7/8" | Buna N | 316 Stainless Steel | 1000 GPM | $289.72 | |
| A | 0500-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 7 3/4" | Buna N | 316 Stainless Steel | 2000 GPM | $348.80 | |
| A | 0600-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 8 3/4" | Buna N | 316 Stainless Steel | 3500 GPM | $504.41 | |
| A | 0800-125WTIBB-T | Cast Iron | - | 250°F | Buna N | 11" | Buna N | 316 Stainless Steel | 6000 GPM | $868.56 |
