| Item | Pilot-Operated Pressure Regulator |
|---|---|
| Adjustable Pressure Range | 10 psi to 100 psi |
| Connection Type | NPT x NPT |
| For Media | Gas, Vapor |
| Height | 14 1/2" |
| Inlet Connection Size | 1 1/2" |
| Inlet Size | 1 1/2" |
| Length | 7 1/4" |
| Max. Operating Pressure | 250 psi |
| Max. Pressure | 250 psi |
| Max. Temp. | 450°F |
|---|---|
| Min. Operating Pressure Differential | 10 psi |
| Operating Temperature Range | 450°F |
| Outlet Size | 1 1/2" |
| Overall Height | 14 1/2" |
| Overall Width | 7 1/4" |
| Pipe Size | 1 1/2" |
| Pressure Adjustment Range | 10 psi to 100 psi |
| Series | E Series |
| Standards | ANSI/FCI 70-2 CLASS IV SHUTOFF, FCI 70-3 CLASS VI SHUTOFF |
| Height (cm) | 33.02 |
|---|---|
| Length (cm) | 47.24 |
| Width (cm) | 29.46 |
| HS Code | 8481809015 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 23.4225 |
| Style | Model | Inlet Size | Outlet Size | Adjustable Pressure Range | Pressure Adjustment Range | Pipe Size | Overall Height | Overall Width | Max. Temp. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | E-C1C9A1B1AH1 | 1/2" | 1/2" | 3 psi to 20 psi | 3 psi to 20 psi | 1/2" | 12 5/8" | 4 3/8" | 450°F | $2,320.01 | |
| A | E-C1D9A1B1AH1 | - | - | 3 psi to 20 psi | 3 psi to 20 psi | 3/4" | 12 7/8" | 4 3/4" | 450°F | $2,425.19 | |
| A | E-C1E9A1B1AH1 | 1" | 1" | 3 psi to 20 psi | 3 psi to 20 psi | 1" | 13 5/8" | 5 3/8" | 450°F | $2,571.95 | |
| A | E-C1F9A1B1AH1 | 1 1/4" | 1 1/4" | 3 psi to 20 psi | 3 psi to 20 psi | 1 1/4" | 13 7/8" | 6 1/2" | 450°F | $3,009.82 | |
| A | E-C1G9A1B1AH1 | 1 1/2" | 1 1/2" | 3 psi to 20 psi | 3 psi to 20 psi | 1 1/2" | 14 1/2" | 7 1/4" | 450°F | $3,465.74 | |
| A | E-C1H9A1B1AH1 | 2" | 2" | 3 psi to 20 psi | 3 psi to 20 psi | - | - | - | 450°F | $4,270.06 | |
| A | E-C1B9A1B1AM1 | 3/8" | - | 10 psi to 100 psi | 10 psi to 100 psi | 3/8" | 12 5/8" | 4 3/8" | 450°F | $2,311.12 |
