| Item | Disc Spring |
|---|---|
| Calculated Load @ Flat | 16.9 lbf. |
| Compatible Hole Diameter | 1/4" |
| Compatible Rod Size | 1/8" |
| Deflection @ Load | 0.004" |
| Disc Type | Belleville Spring |
| Finish | Oil |
| For Hole Size | 1/4" |
| For Rod Size | 0.125" |
| Inside Diameter | 0.13" |
| Load @ Deflection | 12 lbs. |
|---|---|
| Material | Carbon Steel |
| Max. Outside Dia. | 1/4" |
| Min. Inside Dia. | 1/8" |
| Outside Diameter | 1/4" |
| Overall Height | 0.02" |
| Standards | Astm A684 |
| System Of Measurement | Imperial |
| Thickness | 0.008" |
| Type | Belleville |
| Height (cm) | 1.02 |
|---|---|
| Length (cm) | 12.7 |
| Width (cm) | 3.3 |
| HS Code | 7318210090 |
|---|---|
| Weight (kg) | 0.0045 |
| Style | Model | Calculated Load @ Flat | Material | Overall Height | Thickness | Load @ Deflection | Finish | For Hole Size | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | B0187007 | 9.9 lbf. | Carbon Steel | 0.01" | 0.006" | 7 lbs. | Oil | 0.188" | 15 | $46.10 | |
| A | B0187010 | 27.8 lbf. | Carbon Steel | 0.02" | 0.01" | 15 lbs. | Oil | 0.188" | 15 | $46.96 | |
| A | B0250013 | 48 lbf. | Carbon Steel | 0.02" | 0.013" | 26 lbs. | Oil | 1/4" | 25 | $59.19 | |
| A | B0281010 | 23 lbf. | Carbon Steel | 0.02" | 0.01" | 15 lbs. | Oil | 0.281" | 25 | $57.63 | |
| A | B0281013 | 43 lbf. | Carbon Steel | 0.02" | 0.013" | 25 lbs. | Oil | 0.281" | 25 | $57.63 | |
| A | B0281015 | 62 lbf. | Carbon Steel | 0.02" | 0.015" | 34 lbs. | Oil | 0.281" | 25 | $57.63 | |
| A | B0312011 | 27 lbf. | Carbon Steel | 0.02" | 0.01" | 19 lbs. | Oil | 0.313" | 25 | $57.63 |
