| Item | ISO D Die Spring |
|---|---|
| Color | Green |
| Die Spring Color | Green |
| End Type | Closed, Grounded |
| Finish | Chromium |
| Free Length | 10" |
| Inner Dia. | 0.63" |
| Load At Max. Deflection For Long Life | 215.7 lbf. |
| Load At Max. Deflection For Optimal Life | 179.8 lbf. |
| Load Capacity | Not Rated |
| Material | Alloy Steel, Sillicon Wire |
| Max. Deflection | 6.45" |
| Max. Deflection For Long Life | 3" |
| Max. Deflection For Optimal Life | 2.5" |
| Max. Operating Deflection | 4" |
|---|---|
| Operating Temp. Range | Not Rated |
| Outer Dia. | 1.25" |
| Outside Diameter | 1 1/4" |
| Product Type | Die Spring |
| Series | ISO-D Series |
| Solid Length | 3.55" |
| Spring Rate | 71.9 lbs.-in. |
| Spring Rate (stiffness) | 71.9 lbs./in. |
| Spring Shape | Cylindrical |
| System Of Measurement | Imperial |
| Type | Light Duty |
| standard | ASTM A877 |
| Height (cm) | 3.18 |
|---|---|
| Length (cm) | 25.4 |
| Width (cm) | 3.18 |
| HS Code | 7320205060 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 2.4525 |
| Style | Model | Material | Free Length | Solid Length | Outer Dia. | Inner Dia. | Spring Rate (stiffness) | Load Capacity | Finish | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 303104D | Alloy Steel, Sillicon Wire | 63/64" | 0.484" | 0.375" | 0.197" | 70 lbs./in. | Not Rated | Chromium | 10 | $31.70 | |
| A | 303105D | Alloy Steel, Sillicon Wire | 1 17/64" | 0.58" | 0.375" | 0.197" | 56.6 lbs./in. | Not Rated | Chromium | 10 | $28.56 | |
| A | 303106D | Alloy Steel, Sillicon Wire | 1 1/2" | 0.686" | 0.375" | 0.197" | 46.9 lbs./in. | Not Rated | Chromium | 10 | $31.41 | |
| A | 303107D | Alloy Steel, Sillicon Wire | 1 47/64" | 0.782" | 0.375" | 0.197" | 36.8 lbs./in. | Not Rated | Chromium | 10 | $34.40 | |
| A | 303112D | Alloy Steel, Sillicon Wire | 2 63/64" | 1.282" | 0.375" | 0.197" | 24.6 lbs./in. | Not Rated | Chromium | 15 | $61.30 | |
| A | 303148D | Alloy Steel, Sillicon Wire | 12 1/64" | 5.078" | 0.375" | 0.197" | 5.9 lbs./in. | Not Rated | Chromium | 3 | $56.70 | |
| A | 303204D | Alloy Steel, Sillicon Wire | 63/64" | 0.364" | 0.5" | 0.281" | 106 lbs./in. | Not Rated | Chromium | 10 | $28.56 |
