| Item | Manifold |
|---|---|
| Body Finish | Anodized |
| Body Material | Aluminum |
| Color | Black |
| Connection Type | NPT |
| Flow Direction | Inline |
| For Fluid Type | Fluid, Gas |
| Inlet Connection Gender | Female |
| Inlet Connection Size | 1/4" |
| Inlet Connection Type | NPT |
| Inlet Size | 1/4" |
| Manifold Material | Aluminum |
| Manifold Material Finish | Black Anodized |
| Manifold Material Grade | Grade 6061 |
| Manifold Shape | Rectangle |
| Max. Pressure | 1000 psi |
| Maximum Operating Pressure | 3000 psi |
| Maximum Operating Temperature | 200°F |
|---|---|
| Minimum Operating Temperature | -10°F |
| Mounting Hole Diameter | 0.17" |
| Mounting Hole Size | 0.17" |
| Number Of Inlets | 2 |
| Number Of Mounting Holes | 2 |
| Number Of Outlets | 5 |
| Outlet Connection Gender | Female |
| Outlet Connection Type | NPT |
| Outlet Size | 1/8" |
| Outlet Spacing | 3/4" |
| Overall Height | 1" |
| Overall Length | 4" |
| Overall Width | 1" |
| Resistance Properties | Corrosion Resistant, Wear Resistant |
| Temp. Range | -10°F to +200°F |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 10.16 |
| Width (cm) | 2.54 |
| HS Code | 7616995060 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.135 |
| Style | Model | Number Of Inlets | Overall Width | Number Of Outlets | For Fluid Type | Inlet Connection Size | Outlet Spacing | Overall Length | Overall Height | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | M10-125-2 | 2 | 1" | 2 | Fluid, Gas | 1/4" | 3/4" | 1 3/4" | 1" | $28.56 | |
| B | M10-125-3 | 2 | 1" | 3 | Fluid, Gas | 1/4" | 3/4" | 2 1/2" | 1" | $30.67 | |
| C | M10-125-4 | 2 | 1" | 4 | Fluid, Gas | 1/4" | 3/4" | 3 1/4" | 1" | $32.79 | |
| D | M10-125-6 | 2 | 1" | 6 | Fluid, Gas | 1/4" | 3/4" | 4 3/4" | 1" | $37.03 | |
| E | M10-125-7 | 2 | 1" | 7 | Fluid, Gas | 1/4" | 3/4" | 5 1/2" | 1" | $39.40 | |
| F | M10-125-8 | 2 | 1" | 8 | Fluid, Gas | 1/4" | 3/4" | 6 1/4" | 1" | $42.16 | |
| G | M10-125-10 | 2 | 1" | 10 | Fluid, Gas | 1/4" | 3/4" | - | 1" | $45.21 |
