PARKER HALS2V Valve Manifold, 1/2 Inch NPTF Inlet Size | AD7JXJ 4EUJ4 / HALS2V-GR

PARKER HALS2V HALS2V-GR Valve Manifold, 1/2 Inch NPTF Inlet Size

Item: AD7JXJ

Model: HALS2V

Cross Ref: 4EUJ4 / HALS2V-GR

12 In Stock.

Ships within 2 days via

We deliver to your doorstep under DAP terms. Customs clearance is for your account

~~$466.74~~

10% off

$420.07 /unit (ex. VAT)

Add To Cart

Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

Apply Now

FREE delivery on orders over $ 150.00

Payment

Specifications
Product Details
Shipping Information
Working Mechanism
Features
Compatible Accessories
Standards and Approvals
FAQ′s

Specifications

Item	Valve Manifold
Body Material	Stainless Steel
Drain Size	1/4"
Drain Type	FNPT
Height	4"
Inlet Connection	1/2" FNPT
Inlet Size	0.5"
Length	2 1/2"
Material	Stainless Steel
Material Grade	Grade 316
Max. Media Temperature	500°F
Max. Operating Pressure	6000 psi
Media Temp. Range	-65°F to +500°F

Media Temperature Range	-65°F to +500°F
Min. Media Temperature	-65°F
Number Of Valves	2
Outlet Connection	1/2"
Outlet Connection Type	FNPT
Outlet Size	0.5"
Overall Height	4"
Overall Length	63 1/2"
Pressure	6000 psi
Temp. Range	-65°F to +500°F
Vent	0.25"
standard	ANSI CLASS 2500, ANSI CLASS 4500

Product Details

This remote-mount static pressure valve manifold is designed to perform isolation, bleeding and calibration of pressure transmitters, gauges and switches in the oil & gas, petrochemical, chemical, power generation, transportation and nuclear power industries.

Shipping Information

Height (cm)	8.38
Length (cm)	6.35
Width (cm)	10.16

HS Code	8481803090
Country Of Origin	GB
Weight (kg)	0.765

Working Mechanism

Parker HALS2V valve manifold offers a remote mounting design for installation away from the instruments, by using threaded connections.
For use on a pressure transmitter for testing purposes, the process is to open the drain valve and close the block valve.
When the drain valve is opened, connect it to a pressure generator to test pressure.

Features

Parker HALS2V manifold valve features heat-code traceable body and bonnet.
It has an ergonomically designed T-bar handle with positive retention for ease of operation.
The colour coded valve & dust caps help identify and select different configurations. The blue capped valve signifies isolation and the red capped valve signifies bleed / drain.
It is equipped with metal-to-metal seats for ensuring bubble-tight shut-off.
The secure gland lock nut delivers anti-vibration performance.
This unit has seating stem for offering anti-blowout low torque and gland thrust bush to ensure tight sealing & uniform packing compression.
It is offered with PTFree connect style solutions for outlet connections and other ports, including vents.
This connect system enable users to assemble and organise tube lines to any manifold port, even without the need for liquid sealant or PTFE tape.

Compatible Accessories

Parker A-Lok Compression Fittings: They offer optimum speed, reliabilty and ease-of-installation for integral tube connections.

Standards and Approvals

ANSI B16.34 Class 2500
MSS SP-99

Certifications

Frequently Asked Questions

What is the difference between a valve and a manifold?

A manifold is a combination of valves in a single body with separate openings and controls. These manifolds commonly use bleed, needle, ball & vent valves.

Where is the Parker Hannifin headquarters located?

Parker Hannifin's corporate headquarters is located in Mayfield Heights, Ohio, in Greater Cleveland. It was founded in 1917 and has been publicly traded on the NYSE since December 9, 1964.
