| Item | Spiral Point Tap |
|---|---|
| 55% Thread Drill Size | 3.4 mm |
| 65% Thread Drill Size | 3.5 mm |
| 75% Thread Drill Size | 3.3 mm |
| Coolant Fed | Non Coolant Through |
| Extended Neck | Yes |
| Features | Sti Thread |
| Finish | TiCN |
| Interrupted Thread | Yes |
| List Number | 342STI |
| Material Grade - Machining | Grade 342STI |
| Measurement System | Metric |
| Number Of Flutes | 3 |
| Overall Length | 60 mm |
| Pitch Diameter Limits | D3 |
| Pitch Type | 0.7 mm |
| Primary Material Application | Stainless Steel, Steel |
| Primary Material Application Iso Code | M, P |
| Shank Dia. | 4.92 mm |
| Shank Length | 38 mm |
|---|---|
| Shank Type - Machining | Straight |
| Size | M4 |
| Spiral Direction | Neutral |
| Square Size | 3.86 mm |
| Tap Chamfer | Plug |
| Tap Finish | TiCN |
| Tap Material | High Speed Steel |
| Tap Style | Spiral Point |
| Tap Thread Size | M4 x 0.7 |
| Tap Type | Plug |
| Thread Direction | Right Hand |
| Thread Length | 12 mm |
| Thread Limit | D3 |
| Thread Pitch | 0.7 mm |
| Thread Size | M4 x 0.7 |
| Thread Standard | Metric Coarse |
| Thread Type | STI |
| Height (cm) | 1.27 |
|---|---|
| Length (cm) | 7.62 |
| Width (cm) | 1.27 |
| HS Code | 8207400000 |
|---|---|
| Weight (kg) | 0.009 |
| Style | Model | Number Of Flutes | Thread Length | Overall Length | Thread Size | 75% Thread Drill Size | Thread Limit | Pitch Diameter Limits | Shank Dia. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 30100108 | 2 | 19/64" | 1 15/16" | #3-48 | 2 mm | H2 | H2 | 1/8" | $85.36 | |
| A | 30100208 | 2 | 23/64" | 2" | #4-48 | 2.32 mm | H2 | H2 | - | $68.31 | |
| A | 30100308 | 3 | 3/8" | 2 1/8" | #6-40 | #33 | H3 | H2 | 5/32" | $57.17 | |
| A | 30100408 | 3 | 7/16" | 2 3/8" | #8-36 | #29 | H2 | H2 | 7/32" | $57.17 | |
| A | 30100508 | 3 | 37/64" | 2 1/2" | #10-24 | #25 | H2 | H2 | 1/4" | $58.63 | |
| A | 30100608 | 3 | 37/64" | 2 1/2" | #10-24 | #25 | H3 | H3 | 1/4" | $58.63 | |
| A | 30100708 | 3 | 45/64" | 2 23/32" | 1/4"-20 | #7 | H2 | H2 | 5/16" | $75.99 |
