| Item | Radial Ball Bearing |
|---|---|
| Ball Material | Alloy Steel |
| Bearing Industry Number | 608 |
| Bearing Type | Shielded |
| Bore Dia. | 8 mm |
| Cage Material | Steel |
| Cage Type | Pressed |
| Closure | Double Shielded |
| Closure & Seal Type | Double Shielded |
| Dynamic Load Capacity | 750 lbs. |
| Dynamic Radial Load Capacity | 3700N |
| Fillet Radius | 0.3 mm |
| Finish | Chrome Plated |
| Includes Retaining Ring | No |
| Iso Rating | Class 0 |
| Lubricant Material | SRI 2 |
| Lubrication | Sri#2 Grease |
| Maximum Speed | 32000 RPM |
|---|---|
| Maximum Temperature | 120°C |
| Minimum Temperature | -40°C |
| Number Of Rows | 1 |
| Outer Ring Width | 7 mm |
| Outside Dia. | 22 mm |
| Retaining Ring Dia. | Not Applicable |
| Retaining Ring Groove | No |
| Retaining Ring Thickness | Not Applicable |
| Ring Material | Alloy Steel |
| Seal Material | Synthetic Rubber |
| Seal/shield Type | Double Shielded |
| Shield Material | Metal |
| Static Load Capacity | 315 lbs. |
| Static Radial Load Capacity | 1400N |
| System Of Measurement | Metric |
| Width | 7 mm |
| Height (cm) | 2.2 |
|---|---|
| Length (cm) | 2.2 |
| Width (cm) | 0.7 |
| HS Code | 8482105044 |
|---|---|
| Country Of Origin | TW |
| Weight (kg) | 0.018 |
| Style | Model | Bore Dia. | Outside Dia. | Outer Ring Width | Shield Material | Static Radial Load Capacity | Dynamic Radial Load Capacity | Iso Rating | Fillet Radius | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 6205FT150ZZ | 25 mm | 52 mm | 15 mm | Steel | 7850N | 15500N | Class 0 | 1 mm | $50.99 | |
| A | 6201HT200ZZ | 12 mm | 32 mm | 10 mm | Steel | 2750N | 6750N | Class 0 | 0.6 mm | $81.69 | |
| A | 6203HT200ZZ | 17 mm | - | 12 mm | Steel | 4600N | 10600N | Class 0 | 0.6 mm | $130.29 | |
| A | 6206HT200ZZ | 30 mm | 62 mm | 16 mm | Steel | 11300N | 21600N | Class 0 | 1 mm | $195.26 | |
| B | 6204F604 | 20 mm | - | 14 mm | Steel | 6650N | 14200N | Class 0 | 1 mm | $142.43 | |
| B | 6205F604 | 25 mm | 52 mm | 15 mm | Steel | 7850N | 15500N | Class 0 | 1 mm | $164.89 | |
| B | 6206F604 | 30 mm | 62 mm | 16 mm | Steel | 11300N | 21600N | Class 0 | 1 mm | $146.44 |
