| Item | Machinable Fixture Clamps |
|---|---|
| Bolt Thread Length | 20 mm |
| Bolt Thread Size | M10 |
| Clamp Body Material | Steel |
| Clamp Face Material | Steel |
| Clamp Face Type | Smooth |
| Clamp Travel From Centerline | 1.52 mm |
| Clamp Type | Machinable Fixture Clamp |
| Diameter | 10 mm |
| Drive Size | 7 mm |
| Force | 8900N |
| Head Height | 8.9 mm |
|---|---|
| Head Width | 31.2 mm |
| Includes | Machining Screws |
| Material | Steel |
| Max Clamping Force | 8900N |
| Max Machinable Width | 7 mm |
| Measurement System | Metric |
| Number Of Clamps | 4 |
| Overall Height | 26.9 mm |
| Overall Width | 31.2 mm |
| Thread Length | 20 mm |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 12.7 |
| Width (cm) | 20.32 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.234 |
| Style | Model | Force | Material | Overall Width | Thread Length | Overall Height | Diameter | Overall Depth | Drive Size | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 10504 | 800 lbs. | Steel | - | - | 18/25" | 1/4" | - | 1/8" | 4 | $122.73 | |
| A | 10506 | 2000 lbs. | Steel | 1.234" | 3/4" | 1.062" | - | - | 0.188" | 4 | $138.67 | |
| A | 10508 | 4000 lbs. | Steel | 1 12/25" | 1" | 1.35" | 1/2" | - | 5/16" | 4 | $160.89 | |
| A | 10510 | 6000 lbs. | Steel | 1.73" | 1 1/8" | 1.675" | 5/8" | - | 3/8" | 4 | $199.01 | |
| A | 50506 | 3358N | Steel | 24.9 mm | 12 mm | 18.3 mm | 6 mm | - | 4 mm | 4 | $128.19 | |
| A | 50512 | 17800N | Steel | 37.6 mm | 25 mm | 34.3 mm | 12 mm | - | 8 mm | 4 | $172.34 | |
| A | 50516 | 26700N | Steel | 43.9 mm | 30 mm | 42.6 mm | 16 mm | - | - | 4 | $212.34 |
