| Item | Insert |
|---|---|
| Ansi Code | TP-41 |
| Cast Iron Compatibility | Yes |
| Clearance Angle | 10° |
| Corner Radius | 0.0156" |
| Finish | Uncoated |
| Finish - Machining | Bright (Uncoated) |
| Hardened Compatibility | Yes |
| Height | 9/25" |
| Hole Dia. | 0.137" |
| Included Angle | 60° |
| Inscribed Circle | 1/4" |
| Insert Application | Medium |
| Insert Code | TP21.51 |
| Insert Holding Type | Screw |
| Insert Style | Tp |
| Mounting Hole Dia. | 0.137" |
| Mounting Style | Screw On |
| No. Of Cutting Edges | 3 |
|---|---|
| No. Of Edges | 3 |
| Non Ferrous Compatibility | Yes |
| Nose Radius | 0.016" |
| Primary Material Application | Aluminum, Brass, Bronze, Cast Iron, Copper, Hardened Steel, Magnesium, Nickel, Stainless Steel, Steel, Titanium |
| Primary Material Application Iso Code | H, M, N, P, S |
| Radius | 1/64" |
| Rake | Positive |
| Relief Angle | 10° |
| Shape | Triangle |
| Stainless Compatibility | Yes |
| Steel Compatibility | Yes |
| Style | Positive |
| System Of Measurement | Fractional Inch |
| Thickness | 0.094" |
| Through Hole Inside Dia. | 0.137" |
| Workpiece Compatibility | Hardened, Nonferrous, Stainless Steel, Steel, Super Alloy |
| Height (cm) | 0.32 |
|---|---|
| Length (cm) | 0.91 |
| Width (cm) | 0.91 |
| HS Code | 8207806000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.0045 |
| Style | Model | Inscribed Circle | Thickness | Insert Code | Insert Style | Clearance Angle | Corner Radius | Relief Angle | Nose Radius | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | TD-6P-1 | 3/8" | 1/8" | TD321 | TD | 10° | 0.0156" | 10° | 0.016" | $31.06 | |
| A | TD-6P-2 | 3/8" | 1/8" | TD322 | TD | 10° | 0.0312" | 10° | 0.031" | $31.06 | |
| B | TP-42 | 1/4" | 0.094" | TP21.52 | Tp | 10° | 0.0312" | 10° | 0.031" | $28.56 | |
| B | TP-61 | 3/8" | 1/8" | TP321 | Tp | 10° | 0.0156" | 10° | 0.016" | $31.87 | |
| B | TP-62 | 3/8" | 1/8" | TP322 | Tp | 10° | 0.0312" | 10° | 0.031" | $31.44 | |
| C | TPG-222 | 1/4" | 1/8" | - | - | - | - | 11° | 0.031" | $19.84 | |
| C | TPG-321 | 3/8" | 1/8" | TPG321 | TPG | 11° | 0.0156" | 11° | 0.016" | $22.26 |
