| Item | Bulkhead Union |
|---|---|
| Application | Air |
| Basic Material | Plastic |
| Body Material | Glass Filled Nylon |
| Color | Black |
| Connection Type | Tube |
| Fitting Material | Nylon |
| Fitting Side A Connection Type | Push-To-Connect |
| Fitting Side A Tube Outer Diameter | 1/8" |
| Fitting Side B Connection Type | Push-To-Connect |
| Fitting Side B Tube Outer Diameter | 1/8" |
| Hex Size | 13 mm |
| Includes Pre-applied Thread Sealant | No |
| Max. Pressure | 290 psi |
| Maximum Operating Pressure | 290 psi |
|---|---|
| Maximum Operating Temperature | 176°F |
| Minimum Operating Temperature | 4°F |
| Overall Length | 1" |
| Pipe Size | 1/8" |
| Release Type | Button |
| Resistance Properties | Chemical Resistant, Corrosion Resistant |
| Specific Fitting Shape | Straight Bulkhead Union |
| System Of Measurement | Imperial |
| Temp. Range | -4°F to +175°F |
| Tube Size | 1/8" |
| Vacuum Rating | 28 in. hg |
| Standards | 2011/65/EC, DI: 1907/2006 (REACH), DI: 2002/95/EC (ROHS), DI: 97/23/EC (PED), ISO 14743 |
| Height (cm) | 2.79 |
|---|---|
| Length (cm) | 6.35 |
| Width (cm) | 1.27 |
| HS Code | 3917400090 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 0.0225 |
| Style | Model | Fitting Material | Max. Operating Pressure | Fitting Side A Connection Type | Release Type | Fitting Side B Tube Outer Diameter | Fitting Side A Tube Outer Diameter | Vacuum Rating | Overall Length | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 3116 04 00 | Nylon | - | Push-To-Connect | Button | 5/32" | 5/32" | 28 in. hg | 1" | 10 | $134.91 | |
| B | 3116 08 00 | Nylon | - | Push-To-Connect | Button | 5/16" | 5/16" | 28 in. hg | 1 1/2" | 10 | $210.03 | |
| B | 3116 10 00 | Nylon | - | Push-To-Connect | Button | 10 mm | 10 mm | 28 in. hg | 43 mm | 10 | $222.71 | |
| A | 3116 56 00 | Nylon | - | Push-To-Connect | Button | 1/4" | 1/4" | 28 in. hg | 1 3/16" | 10 | $135.79 | |
| A | 3116 60 00 | Nylon | - | Push-To-Connect | Button | 3/8" | 3/8" | 28 in. hg | 1 11/16" | 10 | $206.24 | |
| A | 3116 62 00 | Nylon | - | Push-To-Connect | Button | 1/2" | 1/2" | 28 in. hg | 2 9/32" | 10 | $262.09 | |
| B | 3116 06 00 | Nylon | 290 psi | Push To Connect | Button | 6 mm | 6 mm | 28 in. hg | 28.5 mm | 10 | $156.70 |
