| Item | 200-575 Volt Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps | 0.7A |
| Application Type | Compressor Motors, Fan And Blower Motors, General Purpose Ac Motors |
| Assembly/box Mounting | F1 Only |
| Code | LATER |
| Curvepoint | Break Down |
| Design Code | B |
| Drive End Bearing Size | 6203 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 83% |
| Electrical Type | Squirrel Cage, Inverter Rated |
| Enclosure Type | ODP |
| Frame | 56 |
| Frame Length | 5 1/2" |
| Frame Material | Rolled Steel |
| Frame Size | 56 |
| Frame Suffix | Not Available |
| Frequency | 60 Hz |
| Full Load Amps | 0.7A |
| Grease Type | Polyrex EM |
| Height | 8.63" |
| Hp | 1/2 hp |
| Insulation Class | Class B |
| Inverter Load Ratio | 2:1 |
| Inverter Load Type | Constant |
| Ip Code | IP22 |
| Kva Code | LATER |
| Kw | 0.37 kW |
| Length | 15.63" |
| Load | 1.25 |
| Lubrication | Polyrex EM |
| Material | Rolled Steel |
|---|---|
| Motor Enclosure Design | Dripproof |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Reversible |
| Motor Type | Squirrel Cage Induction Run |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1800 RPM |
| Nema Design | B |
| Nema Rating | NEMA 56 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.37 kW |
| Overall Length | 11 8/25" |
| Packaging | F |
| Phase | 3 |
| Power Factor | 55.5 |
| Resistance Main | 0 ohms |
| Rotation Type | Reversible |
| Rpm | 1725 RPM |
| Service Factor | 1.25 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 22/25" |
| Starting Method | Line Or Inverter |
| Synchronous Rpm | 1800 RPM |
| Thermal Protection | No Protection |
| Torque | 123 lbs.-ft. |
| Torquepct | 0 |
| Type | Continuous Duty |
| Variable Torque Speed Range | 10 |
| Voltage | 575V AC |
| Voltage Rating | 575V AC |
| Height (cm) | 21.92 |
|---|---|
| Length (cm) | 39.7 |
| Width (cm) | 21.92 |
| Country Of Origin | MX |
|---|---|
| Weight (kg) | 13.5 |
