| Item | Metric Motor |
|---|---|
| Ambient Temp. | 40°C |
| Code | H |
| Design | B, H |
| Drive End Bearing Size | 6308 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Efficiency Group | Premium |
| Enclosure Type | Tefc |
| Frame | 132 |
| Frame Material | Cast Iron |
| Frame Type | 132 |
| Frequency | 60 Hz |
| Full Load Amps | 18/9A |
| Hp | 7 1/2 hp |
| Insulation Class | Class F |
| Kw | 5.6 kW |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Shaft Rotation | Reversible |
|---|---|
| Motor Type | Squirrel Cage Inverter Rated |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3600/3000 RPM |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 6306 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 5.6/3.7 kW |
| Packaging | B |
| Phase | 3 |
| Power Factor | 87, 85 |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 1 1/2" |
| Shaft Length | 3.15" |
| Type | TF |
| Voltage | 230/460V |
| Height (cm) | 40.64 |
|---|---|
| Length (cm) | 25.4 |
| Width (cm) | 33.02 |
| Country Of Origin | CN |
|---|---|
| Weight (kg) | 68.4 |
