| Item | Metric Motor |
|---|---|
| Amps | 40A |
| Drive End Bearing Size | 6204 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 77.4% |
| Enclosure Type | IP54 |
| Form Factor | 1 |
| Frame | 80 |
| Frame Type | 80 |
| Full Load Torque | 21 lbs.-in. |
| Grease Type | Polyrex EM |
| Hp | 1 hp |
| Insulation Class | Class F |
| Kw | 0.75 kW |
| Lubrication | Polyrex EM |
| Max. Ambient Temp. | 40°C |
| Motor Application | General Application |
|---|---|
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Mounting | Special |
| Mounting Type | Special |
| Nameplate Rpm | 3000 RPM |
| Opp. Drive End Bearing Size | 6203 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 0.75 kW |
| Packaging | PG659401.08B |
| Power | 0.75 kW |
| Rotation | Reconn |
| Rpm | 3000 RPM |
| Service Factor | 1 |
| Shaft Dia. | 3/4" |
| Shaft Length | 2.05" |
| Voltage | 24V |
| Height (cm) | 27.64 |
|---|---|
| Length (cm) | 49.53 |
| Width (cm) | 26.52 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 14.85 |
