| Item | IEC Pin and Sleeve Connector |
|---|---|
| Amps | 60A |
| Cap Type | Spring Loaded Cap |
| Color | Yellow |
| Compatible With Series | Hbl Heavy Duty |
| Conductor Size | #8 AWG to #2 AWG |
| Connection Orientation | Straight |
| Current Rating | 60A |
| Exposure Conditions | Wateright |
| Face Diameter | 4.15" |
| Features | Color Coded Housings For Easy Identification, Insulated Non Metallic Housing, Self Closing Gasketed Cover |
| For Maximum Cable Diameter | 1.45" |
| Grounding | Grounded |
| Grounding Style | IEC |
| Horsepower Rating | 2 hp |
| Housing Color | Yellow |
| Housing Material | PBT |
| Housing Material Grade | Grade Zytel 801 |
| Ip Rating | IP68, IP69K |
| Market | Industrial |
| Maximum Operating Temperature | 75°C |
| Maximum Wire Size | 2 AWG |
|---|---|
| Minimum Operating Temperature | -40°C |
| Minimum Wire Size | 8 AWG |
| Mounting Style | Cord |
| Nema Enclosure Rating | NEMA 4X |
| Number Of Conductors | 3 |
| Number Of Poles | 2.0 |
| Number Of Wires | 3 |
| Outside Diameter | 4.39" |
| Overall Length | 10.75" |
| Phase | 1 |
| Power Indicating Light | No |
| Resistance Properties | Impact Resistant, Moisture Resistant, Watertight |
| Reverse Service | No |
| Shrouded | Yes |
| Switch Rated | No |
| Ul 94 Flammability Rating | V-0 |
| Voltage | 125V |
| Voltage Rating | 125V AC |
| Wire Connection Type | Screw Terminals |
| Standards | CSA CERTIFIED LR280C, UL CLASSIFIED TO IEC 60309-1 IEC 60309-2, UL E146033 |
| Height (cm) | 11.15 |
|---|---|
| Length (cm) | 27.3 |
| Width (cm) | 11.15 |
| HS Code | 8536904000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 1.305 |
| Style | Model | Current Rating | Amps | Conductor Size | Type | For Maximum Cable Diameter | For Minimum Cable Diameter | Phase | Number Of Poles | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | HBL3100C4W | 100A | 100A | #3 AWG to #1 AWG | Connector | 1.94" | 1.065" | 1 | 2.0 | $1,256.21 | |
| A | HBL330C4W | 30A | 30A | #12 AWG to #8 AWG | Connector | 1.25" | 0.375" | 1 | 2.0 | $583.77 | |
| A | HBL320C4W | - | 20A | #14 AWG to #10 AWG | Female Connector | - | - | 1 | 2.0 | $409.89 |
