| Item | Enclosure |
|---|---|
| Basic Material | Metallic |
| Body Material Thickness | 14 ga. |
| Closure Method | Clamps |
| Color | Silver |
| Compatible Panel Model Number | A24P16G |
| Cover Closure Type | Hinged |
| Cover Style | Solid |
| Cover Type | Hinged Clamp |
| Depth | 8" |
| Enclosure Height | 24" |
| Enclosure Material | Stainless Steel |
| Enclosure Width | 16" |
| Environment | Washdown And Corrosion Resistant |
| Finish | Brushed |
| Gasket | Seamless Foam In Place |
| Gasket Material | Seamless Foam In Place |
| Grade | 304 |
| Ip Rating | IP66 |
|---|---|
| Knockouts | Not Included |
| Knockouts / No Knockouts | No Knockouts |
| Metal Gauge | 14 ga. |
| Mounting | Wall |
| Mounting Type | Wall |
| Nema Enclosure Rating | NEMA 3, NEMA 3R, NEMA 3RX, NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Nema Rating | 3, 3R, 3RX, 4, 4X, 12, 13 |
| Nominal Depth | 8" |
| Nominal Height | 24" |
| Nominal Width | 16" |
| Overall Depth | 8" |
| Overall Height | 24" |
| Overall Width | 16" |
| Panel Height | 21" |
| Panel Width | 13" |
| Product Type | Enclosure |
| Standards | CSA FILE NO 42186: TYPE 4, 4X, 12, CUL LISTED PER CSA C22.2 NO 94, FILE NO E61997, IEC 60529, NEMA/EEMAC TYPE 3, 3R, 4, 4X, 12, 13, UL 508A LISTED |
| Height (cm) | 26.04 |
|---|---|
| Length (cm) | 73.03 |
| Width (cm) | 43.82 |
| HS Code | 8537109050 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 17.1 |
| Style | Model | Enclosure Width | Enclosure Height | Depth | Grade | Cover Type | Enclosure Material | Mounting | Nema Rating | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | A16H1206SSLP | 12" | 16" | 6" | 304 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $1,955.12 | |
| B | A16H1208SSLP | 12" | 16" | 8" | 304 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,011.99 | |
| C | A16H1206SS6LP | 12" | 16" | 6" | Grade 316 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,434.09 | |
| B | A16H1208SS6LP | 12" | 16" | 8" | Grade 316 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,767.54 | |
| B | A16H1606SS6LP | 16" | 16" | 6" | Grade 316 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,880.24 | |
| D | A16H1606SSLP | 16" | 16" | 6" | 304 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,167.19 | |
| B | A20H1606SSLP | 16" | 20" | 6" | 304 | Hinged Clamp | Stainless Steel | Wall | 3, 3R, 3RX, 4, 4X, 12, 13 | $2,571.50 |
