| Item | Enclosure |
|---|---|
| Basic Material | Non Metallic |
| Body Material Thickness | 0.16" |
| Closure Method | Quick Release Latch |
| Color | Light Gray |
| Compatible Panel Model Number | A12P10AL |
| Cover Closure Type | Hinged |
| Cover Style | Solid |
| Cover Type | Hinged |
| Depth | 6" |
| Enclosure Cover Features | Screws |
| Enclosure Height | 12" |
| Enclosure Material | Fiberglass |
| Enclosure Width | 10" |
| Environment | Washdown And Corrosion Resistant |
| Finish | Smooth Matte |
| Gasket | Polyurethane |
| Gasket Material | Polyurethane |
| Ip Rating | IP66 |
|---|---|
| Knockouts | Not Included |
| Knockouts / No Knockouts | No Knockouts |
| Mounting | Wall |
| Mounting Type | Wall |
| Nema Enclosure Rating | NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Nema Rating | NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Nominal Depth | 6" |
| Nominal Height | 12" |
| Nominal Width | 10" |
| Overall Depth | 6" |
| Overall Height | 12" |
| Overall Width | 10" |
| Panel Height | 10.75" |
| Panel Width | 8.88" |
| Product Type | Continuous Hinge Enclosure |
| Standards | CUL LISTED PER CSA C22.2 NO 94, ENCLOSURE FLAMMABILITY EVALUATED PER UL 508A, FILE NO E61997, IEC 60529, MOUNTING BRACKETS REQUIRED TO MEET UL/CSA EXTERNAL MOUNTING REQUIREMENTS, NEMA/EEMAC TYPE 4, 4X, 12, 13, UL 508A LISTED, WINDOW FLAMMABILITY EVALUATED PER UL 508A |
| Height (cm) | 25.4 |
|---|---|
| Length (cm) | 40.64 |
| Width (cm) | 30.48 |
| HS Code | 8538906000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 2.5875 |
| Style | Model | Enclosure Width | Enclosure Height | Depth | Cover Type | Enclosure Material | Mounting | Color | Knockouts / No Knockouts | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | A1086CHSCFG | 8" | 10" | 6" | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $237.77 | |
| A | A14128CHSCFG | 12" | - | 8" | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $316.45 | |
| A | A16148CHSCFG | 14" | 16" | 8" | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $424.56 | |
| A | A181610CHSCFG | 16" | 18" | 10" | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $468.75 | |
| A | A664CHSCFG | 6" | 6" | - | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $192.26 | |
| A | A864CHSCFG | 6" | 8" | 4" | Hinged | Fiberglass | Wall | Light Gray | No Knockouts | $196.04 |
