| Item | Hydraulic Coupler Body |
|---|---|
| Bearing Material | Stainless Steel |
| Bearing Type | Stainless Steel |
| Body Finish | Zinc Plated |
| Body Material | Steel |
| Body Size | 3/8" |
| Connection Type | FSAE |
| Finish | Clear Chromate |
| Flow Rate | 6 GPM |
| Locking Mechanism | Standard Sleeve Lock |
| Max. Pressure | 5075 psi |
| O-ring Thread Size | 3/4"-16 |
| O-ring Thread Type | UNF |
|---|---|
| Operating Temp. Range | -4°F to +212°F |
| Seal Material | Buna N |
| Seal Type | Buna N |
| Seals | Buna N |
| Shut Off | Flat Face |
| Sleeve Material | Zinc Plated Steel |
| Temp. Range | -4°F to +212°F |
| Thread Size | 3/4"-16 |
| Type | Female, Flat Face |
| Valve Design | Tubular Valve |
| Height (cm) | 3.05 |
|---|---|
| Length (cm) | 4.06 |
| Width (cm) | 3.05 |
| HS Code | 7307225000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.2475 |
| Style | Model | Connection Type | Coupling Size | Valve Type | Type | Body Size | Body Material | Temp. Range | Valve Design | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 12FFS75UN | UNF | 1/2" | 2 Way | Female, Flat Face | 1/2" | Steel | -4°F to +212°F | Tubular Valve | $261.77 | |
| A | 12FFS106UN | NPT | 1/2" | 2 Way | Female, Flat Face | 1/2" | Steel | -4°F to +212°F | Tubular Valve | $188.77 | |
| A | 6FFS56UN | UNF | 1/4" | Flush Face | Female, Flat Face | - | Steel | -4°F to +212°F | Tubular Valve | $164.84 | |
| A | 16FFS106UN | UNF | 1/4" | Flush Face | Female, Flat Face | 3/4" | Steel | -4°F to +212°F | Tubular Valve | $406.94 | |
| B | 12FFP106UN | UNF | 1/2" | 2 Way | Flat Face, Male | 1/2" | Steel | -4°F to +212°F | Tubular Valve | $140.07 | |
| B | 6FFP56UN | UNF | 1/4" | Flush Face | Flat Face, Male | - | Steel | -4°F to +212°F | Tubular Valve | $67.87 | |
| B | 12FFP75UN | SAE | 1/2" | 2 Way | Flat Face, Male | 1/2" | Steel | -4°F to +212°F | Tubular Valve | $140.00 |
