DYNABRADE 64207 Downdraft Table 36 x 72 Inch 1 Hp 230v

Item: AD6HLF
Model: 64207
Cross Ref: 45J421
Check Availability
In Stock.

Get it by Friday, Feb 13

£9.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates

We deliver to your doorstep under DAP terms. Customs clearance is for your account

$8,057.60
10% off
$7,251.84 /unit (ex. VAT)
Add To Cart
Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

Payment

Delivery

Specifications

Item Downdraft Table
Air Flow - Maximum 3000 CFM
Application Sanding
Features Dual Filtration, One Heavy Duty Electric Motor, One Pre-Filter Blanket, Two Convenient Dust-Tight Electric Outlets, Two Handy Storage Compartments
Filter Length 25"
Filter Rating 1 µm
Filter Thickness 2"
Filter Width 20"
Fireproof Filter Yes
For Metal Surface No
For Use With Non-Metallic Surfaces
Frequency 60 Hz
Horsepower 1 hp
Includes Pre-Filter Blank
Includes Fireproof Filter Includes Fireproof Filters
Mobility Mobile
Number Of Filters 2
Number Of Motors 1
Overall Height 36"
Overall Width 36"
Phase 1
Sound Level 72 dBA
Table Size 36" x 72"
Table Surface Length 72"
Table Surface Material Coated
Table Surface Width 36"
Voltage 230V
Wattage 746 W

Product Details

Dynabrade 64207 downdraft sanding table removes airborne dust & contaminants generated during sanding operations. It is used with vacuum or non-vacuum sanding tools on non-metallic workpieces. This Dynabrade downdraft table has a 36 X 72 inch (width X length) working surface.

Shipping Information

Height (cm) 91.44
Length (cm) 182.88
Width (cm) 91.44
HS Code 8421398015
Country Of Origin US
Weight (kg) 164.25

Working Mechanism

  • Plug this Dynabrade 64207 downdraft table into a properly grounded outlet with the required electrical supply.
  • Lock the casters in place.
  • Place & fix the workpiece on the unit's tabletop (maximum 250 lb).
  • Turn the table on and begin the operation.
  • The table automatically starts vacuuming the dust & contaminants generated in the operation. Turn off the table after the operation.

Features

  • Dynabrade 64207 downdraft sanding table's tabletop surface has Rhino Linings coating for enhanced durability & anti-slip properties.
  • It offers a dual filtration system by accepting 1-micron pleated filters, one pre-filter blanket (Dynabrade 64986) and one paper filter out of the standard paper air filter (Dynabrade 64671) & UL-Rated Class I non-flammable air filter (Dynabrade 64672).
  • This Dynabrade downdraft table is equipped with two storage compartments for the safe storage of tools & accessories.
  • It has four 5-inch (127 mm) diameter casters for easy manoeuvrability to the desired location.
  • Two dust-tight electric outlets on this unit are used to power different tools.
  • It has a 1 hp (746W) electric motor to offer a maximum airflow of 3000 cfm.

Compatible Accessories

  • Dynabrade 64180 & 64181 Tool Storage Systems: These magnet tool holder / tray units are suitable for storing tools used while sanding.
  • Dynabrade 66310 LED Light Bar: This adjustable 2-position light bar is used to light up the work table.
  • Dynabrade 66347 Replacement Work Surface: This work surface having MAR-Free coating fits over this downdraft table for replacing the damaged work surface.
  • Dynabrade 66311 Accessory Panel Kit: This kit contains a filter-regulator (FR) and a tool manifold to filter out the air while controlling the airflow.

Standards and Approvals

  • UL

Frequently Asked Questions

How to install casters in this Dynabrade 64207 downdraft sanding table?

  • Strap / brace the table to ensure safety while mounting casters in place.
  • Install 4 serrated flange cap screws & 4 locknuts at the bottom of the cabinet assembly for each caster. Locknuts should be installed internally.
  • Use 2 fixed casters at one end of the table & 2 locking swivel casters at the opposite end of the table.
  • After the casters are mounted in place, lower the table on the ground. The downdraft table is now ready for operation.
  • Once the table has reached the desired location, lock both the swivel casters for preventing the table from shifting during operation

What is the sound level of this Dynabrade 64207 downdraft sanding table?

This Dynabrade 64207 downdraft table has a 72 dB sound level.

What is the electrical rating of this Dynabrade 64207 downdraft sanding table?

This Dynabrade 64207 downdraft table accepts 230V, single phase, 60 Hz electrical supply with 7A current.
