| Item | Power Tool Motor |
|---|---|
| Ambient Temp. Range | 40°C |
| Bearing Type | Ball |
| Frame | 56 |
| Frequency | 60 Hz |
| Full Load Amps | 12.4/6.2A |
| Hp | 1 hp |
| Insulation Class | Class A |
| Length Less Shaft | 9 7/16" |
| Max. Ambient Temp. | 40°C |
| Motor Application | Power Tool |
| Motor Bearings | Ball |
| Motor Design | Capacitor Start |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1 |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
|---|---|
| Motor Thermal Protection | Manual |
| Motor Type | Capacitor Start |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 1725 RPM |
| No. Of Speeds | 1 |
| Phase | 1 |
| Service Factor | 1 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1 7/8" |
| Thermal Protection | Manual |
| Usable @ 200v | No |
| Usable @ 208v | No |
| Voltage | 115/230V AC |
| standard | UL COMPONENT RECOGNIZED (E47479) AND CSA CERTIFIED (701887) |
| Height (cm) | 25.4 |
|---|---|
| Length (cm) | 38.1 |
| Width (cm) | 20.32 |
| HS Code | 8501406040 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 13.635 |
| Style | Model | Nameplate Rpm | Thermal Protection | Phase | Hp | Full Load Amps | Service Factor | Voltage | Motor Enclosure Design | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 4K142BB | 1725 RPM | Manual | Single | 1/2 hp | 9.2/4.6A | 1 | 115/230V AC | Open Dripproof | $630.22 | |
| B | 4K144BB | 1750 RPM | Manual | 1 | 3/4 hp | 11.2/5.6A | 1 | 115/230V AC | Open Dripproof | $692.81 | |
| C | 4K145BB | 3450 RPM | Manual | 1 | 1 hp | 12.6/6.3A | 1 | 115/230V AC | Open Dripproof | $705.51 | |
| A | 4K781BB | 1725 RPM | None | 1 | - | 9.2/4.6A | 1.25 | 115/230V AC | Open Dripproof | $590.81 | |
| A | 4K783BB | 1750 RPM | None | 1 | 3/4 hp | 11/5.5A | 1 | 115/230V AC | Open Dripproof | $668.38 |
