| Item | Pedestal Pump |
|---|---|
| Bearing Type | Ball |
| Best Efficiency Flow Rate @ Head | 58 GPM @ 60 ft. |
| Discharge Pipe Type | NPT |
| Discharge Rotation | 360° at 90° Increments |
| Drain Plug | Easily Accessible |
| Duty Cycle | Continuous |
| Flow Rate @ 10 Ft. | 96 GPM |
| Flow Rate @ 25 Ft. | 86 GPM |
| Flow Rate @ 30 Ft. | 83 GPM |
| Flow Rate @ 40 Ft. | 77 GPM |
| Flow Rate @ 50 Ft. | 68 GPM |
| Flow Rate @ 60 Ft. | 58 GPM |
| Flow Rate @ 70 Ft. | 47 GPM |
| Flow Rate @ 80 Ft. | 31 GPM |
| For Use With | Non Flammable And Non-Abrasive Liquid |
| For Use With Potable Systems | No |
| Height | 7 1/2" |
| Housing Material | Polypropylene |
| Hp Required | 2 hp |
| Impeller Material | Polypropylene |
| Impeller Type | Closed |
| Includes | Manual |
| Inlet Pressure | 75 psi |
|---|---|
| Inlet Size | 1 1/2" |
| Intake Pipe Type | NPT |
| Length | 9 1/3" |
| Max. Case Pressure | 100 psi |
| Max. Flow @ 20 Ft. | 89 GPM |
| Max. Flow Rate @ 15 Ft. | 92 GPM |
| Max. Head | 72 ft. |
| Max. Liquid Temp. | 140°F |
| Outlet Size | 1 1/2" |
| Port Rotation | Four Position |
| Screw Material | Stainless Steel |
| Seal Application | Long Life When Not Run Dry Or Pumping Abrasives |
| Seal Material | Buna N, Carbon Ceramic, Stainless Steel |
| Seal Type | Mechanical |
| Shaft Material | Stainless Steel |
| Shaft Outer Dia. | 5/8" |
| Specific Gravity | 1 |
| Type | Chemical Resistant |
| Volute Material | Polypropylene |
| Wetted Material | Buna N, Carbon Ceramic, Polypropylene, Stainless Steel |
| Width | 7 5/8" |
| Height (cm) | 19.05 |
|---|---|
| Length (cm) | 23.7 |
| Width (cm) | 19.3 |
| HS Code | 8413702005 |
|---|---|
| Country Of Origin | IN |
| Weight (kg) | 4.5 |
| Style | Model | Hp Required | Housing Material | Max. Flow @ 20 Ft. | Max. Head | Max. Liquid Temp. | Flow Rate @ 10 Ft. | Max. Flow Rate @ 15 Ft. | Flow Rate @ 30 Ft. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 2YEU9 | 1 hp | Polypropylene | 53 GPM | 79 ft. | 140°F | 55 GPM | 54 GPM | 48 GPM | $1,371.81 | |
| A | 2YEV1 | 1 1/2 hp | Polypropylene | 78 GPM | 72 ft. | 140°F | 85 GPM | 81 GPM | 73 GPM | $1,371.81 | |
| A | 2YEV3 | 3 hp | Polypropylene | 115 GPM | 79 ft. | 140°F | 123 GPM | 119 GPM | 106 GPM | $1,371.81 | |
| B | 2YEX2 | 1 hp | Noryl | 53 GPM | 91 ft. | 180°F | 55 GPM | 54 GPM | 48 GPM | $1,578.30 | |
| B | 2YEX3 | 1 1/2 hp | Noryl | 78 GPM | 91 ft. | 180°F | 85 GPM | 81 GPM | 73 GPM | $1,570.74 | |
| B | 2YEX5 | 3 hp | Noryl | 115 GPM | 95 ft. | 180°F | 123 GPM | 119 GPM | 106 GPM | $1,570.74 | |
| A | 2YEU8 | 3/4 hp | Polypropylene | 33 GPM | 72 ft. | 140°F | 37 GPM | 35 GPM | 29 GPM | $1,463.27 |
