| Item | Tubeaxial Fan |
|---|---|
| Bearing Type | Ball |
| Blade Dia. | 18" |
| Blade Material | Aluminum |
| Body Diameter | 18 1/2" |
| Bolt Circle Diameter | 19 7/8" |
| Brake Horsepower | 1 2/7 bhp |
| Compatible Flange Grainger Part Number | 4C718 |
| Dimension A | 21 1/8" |
| Dimension C | 18 1/2" |
| Dimension D | 16 1/2" |
| Dimension E | 0.312" |
| Drive Type | Belt Drive |
| Features | Factory Installed Cast Iron Sheave Is Assembled On Fan Shaft, Permanently Lubricated Ball Bearings, Rust Protected Steel Housing, Streamlined Belt Tunnel |
| For Air Type | Clean Air |
| Height | 31" |
| Housing Finish | Baked Enamel |
| Housing Material | Steel |
| Includes | Belt Guard |
| Includes Motor & Drive Package | No |
| Max. Ambient Temp. | 104°F |
| Max. Depth | 16 1/2" |
| Max. Inlet Temp. | 200°F |
| Max. Motor Height | 9" |
|---|---|
| Maximum Airflow | 5298 CFM |
| Maximum Fan Speed | 2255 RPM |
| Maximum Motor Hp | 1 1/2 hp |
| Maximum Motor Speed | 2255 RPM |
| Maximum Noise Level @ 5 Feet | 38 sones |
| Maximum Static Pressure | 1 in. wc |
| Minimum Airflow | 3230 CFM |
| Minimum Motor Hp | 33/100 hp |
| Minimum Motor Speed | 1375 RPM |
| Mounting Orientation | Horizontal, Vertical |
| Mounting Position | Horizontal/Vertical |
| Number Of Blades | 6 |
| Overall Diameter | 21 1/8" |
| Overall Height | 31" |
| Overall Length | 16 1/2" |
| Propeller Shaft Diameter | 7/8" |
| Replacement Fan Blade Part No. | 4C715 |
| Replacement Fan Blade Part Number | 4C715 |
| Resistance Properties | Rust Resistant |
| Shaft Dia. | 7/8" |
| Spark Resistant Construction Type | B |
| standard | AMCA SOUND AND AIR |
| Height (cm) | 45.21 |
|---|---|
| Length (cm) | 60.45 |
| Width (cm) | 61.72 |
| HS Code | 8414596090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 26.5275 |
| Style | Model | Voltage | Phase | Cfm @ 0.000-in. Sp | Motor Hp | Dimension E | Bearing Type | Cfm @ 0.125-in. Sp | Full Load Amps | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 7AF47 | 208-230/460V | 3 | 3230 CFM | 1/3 hp | 5/16" | Ball Bearing | 2976 CFM | 1.4-1.6/0.8A | $2,112.74 | |
| A | 7AF48 | 230/460V | 3 | 3230 CFM | 1/3 hp | 5/16" | Ball Bearing | 2976 CFM | 1.2/0.6A | $2,404.75 | |
| A | 7AF49 | 208-230/460V | 3 | 3494 CFM | 1/2 hp | 5/16" | Ball Bearing | 3261 CFM | 2.2/1.1A | $2,150.02 | |
| A | 7AF50 | 208-230/460V | 3 | 3494 CFM | 1/2 hp | 5/16" | Ball Bearing | 3261 CFM | 2.3-2.4/1.2A | $2,463.76 | |
| A | 7AF51 | 208-230/460V | 3 | 4039 CFM | 3/4 hp | 5/16" | Ball Bearing | 3841 CFM | 2.8/1.4A | $2,218.94 | |
| A | 7AF52 | 208-230/460V | 3 | 4039 CFM | 3/4 hp | 5/16" | Ball Bearing | 3841 CFM | 2.3-2.4/1.2A | $2,370.60 | |
| A | 7AF53 | 208-230/460V | 3 | 4671 CFM | 1 hp | 5/16" | Ball Bearing | 4504 CFM | 3.1-2.8/1.4A | $2,577.86 |
