| Item | Coupler |
|---|---|
| Application | Air, Non-Potable Water |
| Bag Qty | 25 |
| Body Dia. | 0.89" |
| Body Material | Acetal |
| Body Type | Bodies |
| Color | White |
| Connection Type | MNPT |
| Coupling Size | 1/4" |
| Finish | Natural |
| Fitting Material | Acetal |
| Fitting Side A Connection Type | Coupler |
| Fitting Side B Connection Type | MNPT |
| Fitting Side B Pipe Size | 1/4" |
| Flow Control Type | Shutoff |
| For Pipe Size | 1/4" |
| Grade | Grade 316 |
|---|---|
| Length | 1.17" |
| Material | Acetal |
| Maximum Operating Pressure | 120 psi |
| Maximum Operating Temperature | 180°F |
| Minimum Operating Temperature | 40°F |
| Mounting Type | Thread |
| Overall Length | 1 5/32" |
| Pressure Range | 0 psi to 120 psi |
| Seal Options | Buna-N |
| Series | PLC Series |
| Specific Fitting Shape | Straight Coupler |
| Standards | Fda Approved, Nsf, Rohs, Usda |
| Temp. Range | -40°F to +180°F |
| Valve Options | Valved |
| Valve Spring Material | Stainless Steel |
| Height (cm) | 2.03 |
|---|---|
| Length (cm) | 2.79 |
| Width (cm) | 2.29 |
| HS Code | 3917400090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.0045 |
| Style | Model | Overall Length | Tube Inside Dia. | Body Dia. | Specific Fitting Shape | Fitting Side A Connection Type | Fitting Side B Connection Type | Fitting Side B Tube Inner Diameter | Fitting Side B Tube Outer Diameter | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | PLCD10006 | 1 5/32" | - | 1.01" | Straight Coupler | Coupler | MNPT | - | - | $26.14 | |
| B | PLCD12004 | 1 7/8" | 0.172" | 1.01" | Panel Mount Coupler | Coupler | Tube | 17/100" | 1/4" | $58.33 | |
| B | PLCD12006 | 1 15/16" | 1/4" | 1.01" | Panel Mount Coupler | Coupler | Tube | 1/4" | 3/8" | $58.27 | |
| C | PLCD13004 | 1 13/16" | 0.172" | 0.93" | Straight Coupler | Coupler | Tube | 17/100" | 1/4" | $41.30 | |
| C | PLCD13006 | 1 15/16" | 1/4" | 0.93" | Straight Coupler | Coupler | Tube | 1/4" | 3/8" | $41.91 | |
| D | PLCD16004 | 1 15/16" | 1/4" | 1.01" | Panel Mount Coupler | Barbed | Coupler | - | - | $54.10 | |
| D | PLCD16005 | 1 15/16" | 0.312" | 1.01" | Panel Mount Coupler | Barbed | Coupler | - | - | $56.94 |
