| Item | Pressure Regulator |
|---|---|
| Body Material | Brass |
| Connection Type | FNPTF x FNPTF |
| Factory Set Pressure | 140 psig |
| For Media | Air, Water |
| Gauge Port | 1/4" |
| Gauge Port Size | 1/4" |
| Height | 4 5/16" |
| Inlet Connection Size | 3/8" |
| Inlet Size | 3/8" |
| Length | 2 1/4" |
| Max. Operating Pressure | 250 psig |
|---|---|
| Max. Pressure | 250 psi |
| Max. Temp. | 180°F |
| Operating Temperature Range | 180°F |
| Outlet Size | 3/8" |
| Overall Height | 4 5/16" |
| Overall Width | 2 1/4" |
| Pipe Size | 3/8" |
| Pressure Adjustment Range | 100 psig to 180 psig |
| Series | A-16 Series |
| Height (cm) | 13.72 |
|---|---|
| Length (cm) | 8.13 |
| Width (cm) | 5.84 |
| HS Code | 8481809015 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.54 |
| Style | Model | Inlet Size | Outlet Size | Pressure Adjustment Range | Pipe Size | Max. Temp. | Connection Type | Gauge Port | Gauge Port Size | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | A16-AWLASBBF01-D5-0140 | 1/4" | 1/4" | 100 psig to 180 psig | 1/4" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $379.93 | |
| A | A16-AWLASBBF01-D2-0030 | 1/4" | 1/4" | 10 psig to 50 psig | 1/4" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $379.93 | |
| A | A16-AWLASBBF01-D1-0016 | 1/4" | 1/4" | 2 psig to 30 psig | 1/4" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $379.93 | |
| A | A16-AWLASBBF01-D3-0058 | 1/4" | - | 25 psig to 90 psig | 1/4" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $379.93 | |
| A | A16-AWLASBBF01-D4-0100 | 1/4" | 1/4" | 80 psig to 120 psig | 1/4" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $379.93 | |
| A | A16-BWLASBBF01-D2-0030 | 3/8" | - | 10 psig to 50 psig | 3/8" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $380.20 | |
| B | A16-BWLASBBF01-D1-0016 | 3/8" | - | 2 psig to 30 psig | 3/8" | 180°F | FNPTF x FNPTF | 1/4" | 1/4" | $380.20 |
