| Item | Fuse |
|---|---|
| Ac Voltage Rating | 600V AC |
| Amps | 60A |
| Body Material | Fiberglass |
| Body Style | Cylindrical |
| Class | Class RK5 |
| Compatible Fuse Block Series | 1Br, R600 |
| Compatible With | 1BR, R600 Series |
| Dc Voltage | 250V DC |
| Dc Voltage Rating | 250V AC |
| Diameter | 1 1/16" |
| Element | Dual |
| Equivalent Brand And Series | Bussmann Frs-R, Edison Ecsr, Littelfuse Flsr, Mersen Trs-R Series |
| Equivalent Series | Ecsr, Flsr, Frs-R, Trs-R |
| Fits Fuse Block Style | Rejection |
|---|---|
| Functionally Equal To | Ferraz/Gould TRS, Littlefuse FLSR |
| Fuse Block Design | Rejection |
| Fuse Holder Code | Q |
| Fuse Size | 5 1/2" x 1 1/16" |
| Indicating / Nonindicating | Nonindicating |
| Interrupt Rating | 200 kA @ 600V AC, 20 kA @ 250V DC |
| Rejection / Nonrejection | Rejection |
| Series | FRS-R Series |
| Speed | Time Delay |
| Speed Type | Time Delay |
| Standards | Ce, Csa Certification Class 1422-01, Ul 248-12 Guide Jddz |
| Visual Indication | Non Indicating |
Bussmann FRS-R-60 fuse is used in power distribution plants, HVAC systems and data centres to provide overcurrent protection.
| Height (cm) | 7.32 |
|---|---|
| Length (cm) | 33.99 |
| Width (cm) | 7.32 |
| HS Code | 8536100040 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 1.62 |
The time-delay feature in the fuse allows it to withstand short-duration overcurrents that might occur during motor starting or other initial power surges.
The dual-element design enhances the fuse's capability to handle different types of overcurrent conditions effectively, improving its overall performance and reliability.
The Class RK5 indicates that the fuse has a time-delay characteristic, allowing it to tolerate short-duration overcurrent conditions during startup or inrush currents.
It has a response time of 10 seconds at 500%.
| Style | Model | Amps | Body Style | Diameter | Dc Voltage Rating | Dc Voltage | Body Material | Element | Indicating / Nonindicating | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | FRS-R-1-1/4 | 1.25A | Cylindrical | 13/16" | 300V DC | - | Fiberglass | Dual | Nonindicating | $25.62 | |
| B | FRS-R-5 | 5A | Cylindrical | 13/16" | 300V DC | 300V DC | Fiberglass | Dual | Nonindicating | $25.62 | |
| A | FRS-R-15 | 15A | Cylindrical | 13/16" | 300V DC | - | Fiberglass | Dual | Nonindicating | $20.53 | |
| A | FRS-R-20 | 20A | Cylindrical | 13/16" | 300V DC | - | Fiberglass | Dual | Nonindicating | $20.53 | |
| A | FRS-R-25 | 25A | Cylindrical | 13/16" | 300V DC | - | Fiberglass | Dual | Nonindicating | $20.53 | |
| A | FRS-R-30 | 30A | Cylindrical | 13/16" | 300V DC | - | Fiberglass | Dual | Nonindicating | $20.53 | |
| C | FRS-R-65 | 65A | Blade | 1 1/8" | 300V DC | - | Fiberglass | Dual | Nonindicating | $122.80 |
