| Item | Power Distribution Block |
|---|---|
| Depth | 2 3/25" |
| Flammability Rating | V-0 |
| For Conductor Material | Aluminum, Copper |
| For Maximum Line Wire Size | 350 kcmil |
| For Maximum Load Wire Size | 350 kcmil |
| For Minimum Line Wire Size | 6 AWG |
| For Minimum Load Wire Size | 6 AWG |
| Length | 2 4/5" |
| Line Connections/pole | 1 |
| Line Side Connection Type | Lug |
| Load Connections/pole | 1 |
| Load Side Connection Type | Lug |
| Max. Amps | 310A |
|---|---|
| Maximum Operating Temperature | 248°F |
| Maximum Voltage | 600V AC/DC |
| Number Of Poles | 2 |
| Overall Depth | 1.84" |
| Overall Length | 2.45" |
| Overall Width | 3 23/25" |
| Power Distribution Block Design | Open |
| Secondary Connection/pole | 1 |
| Secondary Wire Size Range | 6 AWG to 350 mcm |
| Standards | Csa Class 6228-01, Ul 1059 |
| Terminal Material | Aluminum, Copper |
| Width | 4 3/25" |
| Height (cm) | 11.68 |
|---|---|
| Length (cm) | 8.64 |
| Width (cm) | 6.1 |
| HS Code | 8536904000 |
|---|---|
| Country Of Origin | MX |
| Weight (kg) | 0.63 |
| Style | Model | Number Of Poles | Max. Amps | Secondary Wire Size Range | Overall Length | For Conductor Material | Depth | Housing Color | Secondary Connection/pole | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 16003-2 | 2 | 255A | 6 AWG to 250 mcm | 5.37" | Aluminum, Copper | 2 3/25" | - | 1 | $285.53 | |
| A | 16005-3 | 3 | 310A | 6 AWG to 350 mcm | 2.68" | Aluminum, Copper | 2 3/25" | Black | 1 | $269.43 | |
| A | 16003-3 | 3 | 255A | 6 AWG to 250 mcm | 5.37" | Aluminum, Copper | 2 3/25" | Black | 1 | $417.34 |
