| Item | Swivel Plate Caster |
|---|---|
| Application | General / Industrial / Commercial / Institutional purpose |
| Bearing Type | Double Ball |
| Caster Brake Included | No |
| Caster Brake Type | No Brake Included |
| Caster Frame Material | Steel |
| Caster Load Rating Range | 300 lbs. to 999 lbs. |
| Caster Material | Nylon |
| Caster Product Group | Swivel Caster |
| Caster Sub-type | Swivel |
| Caster Wheel Material | Nylon |
| Core Color | White |
| Core Material | Nylon |
| Durometer | 70 Shore D |
| Extended Lead | No |
| Features | Center Rubber Damping Ring |
| Frame Finish | Zinc Plated |
| Frame Material | Steel |
| Hole Pattern | A |
| Includes Thread Guards | Yes |
| Inside Bolt Hole Spacing | 2 3/8" x 3 5/32" |
| Load Rating | 330 lbs. |
| Lock Type | No Lock Included |
| Mounting Bolt Dia. | 5/16" |
| Mounting Height | 4 7/8" |
| Mounting Plate Bolt Hole Pattern | D |
| Mounting Plate Size | 3 3/8" x 3 15/16" |
| Mounting Plate Size & Bolt Hole Pattern | 3 3/8" X 3 15/16" ( D ) |
| Non-marking | Yes |
|---|---|
| Number Of Mounting Holes | 4 |
| Number Of Wheels | 1 |
| Outside Bolt Hole Spacing | 2 3/8" x 3 5/32" |
| Overall Height | 4.938" |
| Plate Size | 3 3/8" x 3 15/16" |
| Plate Thickness | 0.093" |
| Plate Type | A |
| Raceway Type | Double Ball |
| Replacement Wheel | POW 100/8K-FK |
| Standards | Din En 12532, Iso 14001, Iso 5001, Iso 9001 |
| Swivel Construction | Kingpin |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Double Ball |
| Swivel Radius | 0.0" |
| Tread Shape | Standard |
| Wheel Bearing Type | Precision Ball |
| Wheel Bearings | Precision Ball |
| Wheel Color | White |
| Wheel Core Material | Nylon |
| Wheel Dia. | 3 15/16" |
| Wheel Diameter | 4" |
| Wheel Material | Nylon |
| Wheel/tread Color | White |
| Wheel/tread Hardness | 70 Shore D |
| Wheel/tread Hardness Rating | Hard |
| Wheel/tread Material | Nylon |
| Height (cm) | 12.7 |
|---|---|
| Length (cm) | 13.97 |
| Width (cm) | 8.13 |
| HS Code | 8302200000 |
|---|---|
| Country Of Origin | DE |
| Weight (kg) | 0.72 |
| Style | Model | Mounting Plate Bolt Hole Pattern | Inside Bolt Hole Spacing | Outside Bolt Hole Spacing | Wheel/tread Material | Wheel Bearing Type | Load Rating | Mounting Height | Mounting Plate Size | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | LE-POW 125KF | D | 2 3/8" x 3 5/32" | 2 3/8" x 3 5/32" | Nylon | Precision Ball | 330 lbs. | 5 7/8" | 3 3/8" x 3 15/16" | $67.11 | |
| B | LPA-VSTH 35K | B | 1 1/2" x 1 1/2" | 1 7/8" x 1 7/8" | Polyurethane | Precision Ball | 220 lbs. | 2" | 2 3/8" x 2 3/8" | $28.09 | |
| C | LPXA-VPA 50G | B | 1 1/2" x 1 1/2" | 1 7/8" x 1 7/8" | Rubber | Plain | 85 lbs. | 2 13/16" | 2 3/8" x 2 3/8" | $56.72 | |
| C | LPXA-VPA 75G | B | 1 1/2" x 1 1/2" | 1 7/8" x 1 7/8" | Rubber | Plain | 130 lbs. | 3 7/8" | 2 3/8" x 2 3/8" | $64.11 | |
| D | LIX-POHI 100G | D | 2 3/8" x 3 5/32" | 2 3/8" x 3 5/32" | Nylon | Plain | 330 lbs. | 4 7/8" | 3 15/16" x 3 15/16" | $108.04 | |
| D | LIK-POHI 125G-1 | D | 2 3/8" x 3 5/32" | 2 3/8" x 3 5/32" | Nylon | Plain | 660 lbs. | 6 1/8" | 3 15/16" x 3 15/16" | $115.41 | |
| E | LO-SE 125K | C | 2 15/16" x 4 1/8" | 3 5/32" x 4 9/64" | Rubber | Precision Ball | 705 lbs. | 6 11/16" | 4 5/16" x 5 1/2" | $238.72 |
