| Item | Vector Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Base Indicator | Rigid |
| Base Rpm | 1800 RPM |
| Base Type | Rigid Base |
| Conduit Box Material | Cast Iron |
| Conduit Box Position | F1 |
| Constant Torque | 1000:1 |
| Design Code | A |
| Duty | Continuous |
| Enclosure Design | TEFC |
| Frame | 254TC |
| Frame Material | Iron |
| Frame Size | 254TC |
| Frequency | 60 Hz |
| Full Load Amps | 36/18A |
| Hp | 15 hp |
| Insulation Class | Class F |
| Inverter Code | Inverter Duty |
| Leads | 9#12 |
| Magnetizing Amps | 13.9/6.95A |
| Max. Rpm | 2700 RPM |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Mounting Position | Horizontal |
| Motor Type | Three Phase |
|---|---|
| Mounting Type | Rigid Base |
| Multiplier | E2 |
| Nema/iec | NEMA |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 92.4% |
| Overall Length | 26.91" |
| Phase | 3 |
| Power Factor | 84 |
| Proprietary | No |
| Pulley Face Code | C Face |
| Revision | A |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1 5/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Synchronous Rpm | 1800 RPM |
| Type | 0942M |
| Voltage | 230/460V |
| Wire Size | 12 AWG |
| Xp Class And Group | None |
| Height (cm) | 49.85 |
|---|---|
| Length (cm) | 78.74 |
| Width (cm) | 60.32 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 132.75 |
| Style | Model | Voltage | Hp | Full Load Amps | Frame | Nameplate Rpm | Nominal Efficiency | Max. Rpm | Overall Length | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | ZDVSM2334T | 230/460V | 20 hp | 48/24A | 256TC | - | 93% | 2700 RPM | 26.91" | $9,895.16 | |
| A | ZDVSM3661T | 230/460V | 3 hp | 8.2/4.1A | 182TC | - | 89.5% | 5400 RPM | 20.23" | $5,844.87 | |
| A | ZDVSM3665T | 230/460V | 5 hp | 13.2/6.6A | 184TC | 1750 RPM | 89.5% | 4000 RPM | 20.23" | $6,286.44 | |
| A | ZDVSM3770T | 230/460V | 7 1/2 hp | 19/9.5A | 213TC | 1770 RPM | - | 4000 RPM | 24.59" | $7,213.09 | |
| A | ZDVSM3774T | 230/460V | 10 hp | 25/12.5A | 215TC | - | 92.4% | 4500 RPM | 24.59" | $8,477.99 | |
| A | ZDVSM4103T | 230/460V | 25 hp | 60/30A | 284TC | 1775 RPM | 93.6% | 2700 RPM | 30.42" | $11,739.76 | |
| A | ZDVSM4104T | 230/460V | 30 hp | 72/36A | 286TC | 1770 RPM | 94.1% | 2700 RPM | 30.42" | $12,543.51 |
