| Item | General Purpose Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 2.5/1.25A |
| Amps @ 208v | 1.6A |
| Base Indicator | Rigid |
| Base Type | Rigid Base |
| Break-down Torque | 0.55 lbs.-ft. |
| Code | M |
| Conduit Box Position | F1 |
| Duty | Continuous |
| Enclosure Design | TEFC |
| Frame | 42 |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 2.5/1.25A |
| Full Load Torque | 0.2 lbs.-ft. |
| Hp | 13/100 hp |
| Insulation Class | Class B |
| Inverter Code | Not Inverter |
| Lead | 6#18 |
| Line-line Res. @ 25° C | 16.2 ohms A Ph/12.2 ohms B Ph |
| Locked-rotor Torque | 0.89 lbs.-ft. |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Motor Type | Capacitor Start/Induction Run |
| Mounting Type | Foot Mounted |
| Multiplier | K |
| Nameplate Rpm | 3450 RPM |
|---|---|
| Nema/iec | NEMA |
| No Load Amps | 1.05A |
| No. Of Motor Leads | 6 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 45% |
| Overall Length | 9.56" |
| Phase | 1 |
| Power Factor | 62 |
| Proprietary | No |
| Pull-up Torque | 0.47 lbs.-ft. |
| Pulley Face Code | Standard |
| Revision | Z |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.4 |
| Shaft Dia. | 3/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 5.65A |
| Synchronous Rpm | 3600 RPM |
| Temp. Rise @ Rated Load | 37°C |
| Temp. Rise @ S. F. Load | 44°C |
| Type | 3310L |
| Voltage | 115/230V |
| Wire Size | 18 AWG |
| Height (cm) | 23.81 |
|---|---|
| Length (cm) | 35.09 |
| Width (cm) | 27.47 |
| HS Code | 85013100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 6.75 |
