| Item | Pipe |
|---|---|
| Application | Air, Natural Gas, Oil, Potable Water, Steam |
| Color | Red |
| Connection | Threaded On Both End |
| Connection Type | Threaded On Both Ends |
| Fitting Compatibility | Class 300 |
| Gravity Flow | No |
| Inside Diameter | 1/4" |
| Length | 36" |
| Material | Red Brass |
| Material Grade | Astm B43 |
| Maximum Operating Pressure | 282 psi @ 450°F |
| Maximum Operating Temperature | 400°F |
| Maximum Steam Pressure | 282 psi @ 450°F |
| Metal Pipe Construction | Seamless |
| Minimum Operating Temperature | -20°F |
| Nominal Pipe Size | 1/4" |
| Outside Dia. | 1/2" |
|---|---|
| Overall Length | 3 ft. |
| Pipe Size | 1/4" |
| Pressure | 250 psi |
| Resistance Properties | Corrosion Resistant |
| Schedule | 80 |
| Side A Connection Type | Threaded |
| Side A Gender | Male |
| Side A Thread Type | NPT |
| Side B Connection Type | Threaded |
| Side B Gender | Male |
| Side B Thread Type | Npt |
| Standards | Astm B43, Nsf 372, Nsf 61 |
| Temp. Range | -20°F to +400°F |
| Thread Configuration | Threaded On Both Ends |
| Wall Thickness | 0.123" |
| Height (cm) | 1.37 |
|---|---|
| Length (cm) | 91.44 |
| Width (cm) | 1.37 |
| HS Code | 7411211000 |
|---|---|
| Country Of Origin | CN |
| Weight (kg) | 0.7844 |
| Style | Model | Schedule | Pressure | Connection Type | Pipe Size | Outside Dia. | Connection | Material | Overall Length | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 461-180X | 80 | 250 psi | Threaded On Both Ends | 1/4" | 1/2" | Threaded On Both End | Red Brass | 18" | $106.19 | |
| B | 462-180X | 80 | 250 psi | Threaded On Both Ends | - | 0.667" | Threaded On Both End | Red Brass | 18" | $127.86 | |
| B | 463-180X | 80 | 250 psi | Threaded On Both Ends | 1/2" | 0.812" | Threaded On Both End | Red Brass | 18" | $154.63 | |
| B | 464-180X | 80 | 250 psi | Threaded On Both Ends | 3/4" | 1" | Threaded On Both End | Red Brass | 18" | $195.16 | |
| A | 462-240X | 80 | 250 psi | Threaded On Both Ends | - | 0.667" | Threaded On Both End | Red Brass | 2 ft. | $125.07 | |
| A | 463-240X | 80 | 250 psi | Threaded On Both Ends | 1/2" | 0.812" | Threaded On Both End | Red Brass | 2 ft. | $212.66 | |
| A | 464-240X | 80 | 250 psi | Threaded On Both Ends | 3/4" | 1" | Threaded On Both End | Red Brass | 2 ft. | $264.13 |
