| Item | Machine Screw |
|---|---|
| Dimensional Standards | Ansi/Asme B18.6.3 |
| Drive | Phillips |
| Drive Size | #2 |
| Drive Type | Phillips |
| Fastener Length | 1/2" |
| Finish | Plain |
| Grade | Grade 18-8 |
| Head And Washer Height | 7/64" |
| Head Dia. | 0.27" |
| Head Height | 0.082" |
| Head Type | Pan |
| Includes Washer | Yes |
| Length | 1/2" |
|---|---|
| Material | Stainless Steel |
| System Of Measurement | Imperial |
| Thread Size | #6-32 |
| Thread Type | Coarse |
| Type | Machine Screw |
| Washer Material | Stainless Steel |
| Washer Material Grade | Grade 410 |
| Washer Outside Dia. | 8/25" |
| Washer Outside Diameter | 0.32" |
| Washer Thickness | 0.03" |
| Washer Type | Dual Action Spring Washer |
| Height (cm) | 3.3 |
|---|---|
| Length (cm) | 6.6 |
| Width (cm) | 5.33 |
| HS Code | 7318154000 |
|---|---|
| Country Of Origin | TW |
| Weight (kg) | 0.0405 |
| Style | Model | Thread Size | Head Height | Thread Type | Head Dia. | Tensile Strength | Thread Length | Class | Drive Size | Pkg. Qty. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1PXE8 | 1/4"-20 | 0.144" | Coarse | 0.492" | - | 1/2" | - | #3 | 5 | $5.44 | |
| B | 1PXJ7 | #2-56 | 0.053" | Coarse | 0.167" | - | 1/2" | - | #1 | 50 | $31.79 | |
| B | 1PXK5 | #4-40 | 0.068" | Coarse | 0.219" | - | 5/8" | - | #1 | 50 | $22.14 | |
| C | 1ZA99 | #0-80 | 0.044" | Fine | 0.116" | 60000 psi | - | Class 2A | #0 | 100 | $12.37 | |
| D | 1ZB13 | #0-80 | 0.044" | Fine | 0.116" | 60000 psi | - | Class 2A | #0 | 100 | $28.56 | |
| E | 1ZB18 | #1-72 | 0.053" | Fine | 0.142" | 60000 psi | 3/16" | Class 2A | #0 | 100 | $17.21 | |
| F | 1ZB19 | #1-72 | 0.053" | Fine | 0.142" | 60000 psi | 1/4" | Class 2A | #0 | 100 | $14.27 |
