ALLEGRO SAFETY

ALLEGRO SAFETY 9539-12 Confined Space Blower, Axial, 3425 RPM, 115V AC, 1 HP

Item: AE3YRG
Model: 9539-12
Cross Ref: 5GVX4
Check Availability
In Stock

Get it by Monday, Mar 2

£9.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates

We deliver to your doorstep under DAP terms. Customs clearance is for your account

$806.94
5% off
$766.59 /unit (ex. VAT)
Add To Cart
Request Quote

Unlock 30-day payment terms

Business customers can apply for Net 30
No fees, No interest, Fast approval.

Apply Now

Payment

Delivery

Specifications

Item Confined Space Blower
Blower/fan Speed 3400 RPM
Color Orange
Current 7.1A
Duct Dia. 12"
Fan Material Polypropylene
Finish PVC Coated
Frequency 60 Hz
Height 21"
Hp 1 hp
Length 17"
Material Nylon, Polyester, Polypropylene, PVC, Steel, Vinyl
Material Properties UV And Chemical Resistant
Max. Flow In Free Air 2180 CFM
Max. Rpm 3400 RPM
Number Of Blades 6
Operating Voltage 115V AC
Phase 1
Type Axial
Width 14"
standard CSA CERTIFIED, UL RECOGNIZED

Shipping Information

Height (cm) 55.88
Length (cm) 53.34
Width (cm) 38.1
HS Code 8414519090
Country Of Origin CN
Weight (kg) 17.73

Working Mechanism

  • Connect the blower to a 115VAC power source using the appropriate power cord and ensure a stable electrical connection.
  • Turn on the blower using the power switch or control panel, activating the 1 hp motor.
  • The motor drives the axial fan at a high speed of up to 3425 rpm. As the fan blades rotate, they draw in air from the surrounding environment.
  • The rotating blades create a low-pressure zone near the inlet side of the blower, allowing ambient air to be drawn into the blower unit.
  • The captured air is accelerated and directed towards the outlet side of the blower as it encounters the high-speed rotating blades.
  • The accelerated air is forcefully discharged through the blower's outlet, creating a strong and consistent airflow.
  • The generated airflow can be directed towards the desired area or connected to ventilation ducts for efficient air distribution in confined spaces or work environments.

Compatible Accessories

  • Allegro Lay Flat Ducting: These clear polyethene lightweight air ventilation tubing are designed to deliver high volumes of forced air effectively to confined areas. They have durable construction and tubing to resist splitting & tearing while offering exceptional toughness, elasticity and flexibility.

Standards and Approvals

  • UL
  • CSA

Documentation

Certifications

certificatecertificate

Frequently Asked Questions

Can a blower be placed vertically above a manhole?

Yes, if it is supported safely, with adequate ingress / egress, vibration, movement and weight mitigation.

How long should you ventilate a confined space?

According to AIHA (American Industrial Hygiene Association), the acceptable practice for a confined space is 20 complete air changes per hour or one every 3 minutes.

How to install this blower?

  • Select a suitable mounting location for the blower installation.
  • Prepare the mounting surface by ensuring it is clean and level.
  • Attach any necessary mounting accessories or brackets to the blower.
  • Position the blower in the desired location, aligning it with the mounting surface or accessories.
  • Securely fasten the blower to the mounting surface or accessories using appropriate hardware.
  • Connect the blower to a 115 VAC power source with the correct power cord.
  • Follow safety precautions and regulations for grounding and electrical safety.
  • Test the blower's operation by turning it on and checking for smooth running.
  • Adjust the airflow direction if applicable, directing it towards the desired area.
  • Verify that the blower effectively ventilates the space or connected ventilation ducts without any obstructions.

Can a blower be placed vertically above a manhole?

Yes, if it is supported safely, with adequate ingress / egress, vibration, movement and weight mitigation.

How long should you ventilate a confined space?

According to AIHA (American Industrial Hygiene Association), the acceptable practice for a confined space is 20 complete air changes per hour or one every 3 minutes.

What factors should be considered while choosing Allegro 9539-12 plastic blower?

  • Consider the specific ventilation needs of your application.
  • Assess the environmental conditions in which the blower will operate.
  • Verify that the blower's power specifications match the available power source.
  • Evaluate the blower's airflow capacity in relation to your ventilation requirements.
  • Determine if the blower offers adjustable speed settings or control options.
  • Assess the durability and construction of the blower for suitability in the operating environment.
  • Evaluate the blower's portability and mounting options.
  • Consider the noise level generated by the blower during operation.
  • Review any safety features incorporated into the blower design.
  • Research the reputation and reliability of the manufacturer for customer support and warranty coverage.
