| Item | Illuminated Push Button |
|---|---|
| Action | Momentary |
| Basic Material | Plastic |
| Bezel Material | Plastic |
| Cad Overall Depth | 34 mm |
| Cad Overall Height | 30 mm |
| Cad Overall Width | 30 mm |
| Cap/operator Or Lens Colour | White |
| Color | White |
| Device Presentation | Basic Element |
| Features | Snap Fit Assembly, Withstands Harsh Environments |
| Head Material | Plastic |
| Head/lens Color | White |
| Ip Rating | IP66 |
| Lamp Bulb Type | No Lamp Module Included |
| Lamp Module Type | No Lamp Module Included |
| Lamp Module Voltage | Module Not Included |
| Lamp Type | LED |
| Lamp Voltage | Dependent On Module Used |
| Legend | No Legend |
| Manufacturer Warranty Length | 18 Months |
| Mounting Diameter | 22 mm |
|---|---|
| Nema Enclosure Rating | NEMA 1, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12, NEMA 13 |
| Nema Rating | NEMA 13, NEMA 4X |
| Number Of Indicator Lights | 1 |
| Number Of Operators | 1 |
| Operating Temperature - Maximum | 158°F |
| Operating Temperature - Minimum | -40°F |
| Operator Illumination | Illuminated |
| Operator Material | Plastic |
| Overall Depth | 1.34" |
| Overall Height | 1.18" |
| Overall Width | 1.18" |
| Panel Mounting Hole Diameter | 22 mm |
| Product Type | Push Button Operators |
| Push Button Style | Extended |
| Resistance Properties | Dust Resistant, Impact Resistant, Vibration Resistant, Watertight |
| Series | XB5 Series |
| Shape Of Signaling Unit Head | Square |
| Type Of Operator | Square Extended Button |
| Standards | BUREAU VERITAS, CLASS II IEC 60536, CSA C22.2 NO.14, DNV, EN 50102, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, GB 14048.5, GL, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C8201-1, JIS C8201-5-1, LROS, REACH FREE OF SVHC, ROHS, UL 508 |
| Height (cm) | 5.59 |
|---|---|
| Length (cm) | 4.57 |
| Width (cm) | 5.33 |
| HS Code | 8538906000 |
|---|---|
| Country Of Origin | FR |
| Weight (kg) | 0.045 |
| Style | Model | Head Material | Lamp Module Type | Basic Material | Ip Rating | Bezel Material | Bezel | Nema Rating | Lamp Voltage | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | ZB5CW343 | Plastic | No Lamp Module Included | Plastic | IP66 | Plastic | - | NEMA 13, NEMA 4X | Dependent On Module Used | $50.70 | |
| B | ZB5AW15 | Plastic | No Lamp Module Included | Plastic | IP66 | Plastic | - | NEMA 13, NEMA 4X | Dependent On Module Used | $26.51 | |
| C | ZB5CW333 | Plastic | No Lamp Module Included | Plastic | IP66 | Plastic | - | NEMA 13, NEMA 4X | Dependent On Module Used | $52.36 | |
| D | ZB5CW313 | Plastic | No Lamp Module Included | Plastic | IP66 | Plastic | - | NEMA 13, NEMA 4X | Dependent On Module Used | $48.91 | |
| E | ZB4BW613 | Metal | No Lamp Module Included | Metal | IP66 | Metal | Chrome Plated Metal | NEMA 13, NEMA 4X | Dependent On Module Used | $89.54 | |
| F | ZB4BW633 | Metal | No Lamp Module Included | Metal | IP66 | Metal | Chrome Plated Metal | NEMA 13, NEMA 4X | Dependent On Module Used | $87.41 | |
| G | ZB5AW733 | Plastic | Transformer | Plastic | - | - | - | NEMA 13, NEMA 4X | Dependent On Module Used | $123.54 |
