| Item | Rigid Plate Caster |
|---|---|
| Application | Kingpinless Casters |
| Caster Brake Included | No |
| Caster Brake Type | No Brake Included |
| Caster Frame Material | Steel |
| Caster Load Rating Range | 1000 lbs. to 2999 lbs. |
| Caster Material | Nylon |
| Caster Product Group | Rigid Caster |
| Caster Sub-type | Rigid |
| Caster Temp. Range Available | Yes |
| Caster Type | Rigid |
| Caster Wheel Material | Nylon |
| Core Color | White |
| Core Material | Nylon |
| Durometer | 80 Shore D |
| Extended Lead | No |
| Frame Finish | Zinc |
| Frame Material | Steel |
| Hole Pattern | B |
| Includes | Top Grease Seal |
| Includes Thread Guards | No |
| Inside Bolt Hole Spacing | 2 5/8" x 3" |
| Load Rating | 2200 lbs. |
| Lock Type | No Lock Included |
| Mounting Bolt Dia. | 3/8" |
| Mounting Height | 9 1/2" |
| Mounting Plate Bolt Hole Pattern | A |
| Mounting Plate Size | 4" x 4 1/2" |
|---|---|
| Mounting Plate Size & Bolt Hole Pattern | 4" X 4 1/2" ( A ) |
| Non-marking | Yes |
| Number Of Mounting Holes | 4 |
| Number Of Wheels | 1 |
| Operating Temp. Range | -4°F to +176°F |
| Outside Bolt Hole Spacing | 3" x 3 5/8" |
| Overall Height | 9 1/2" |
| Plate Size | 4" x 4 1/2" |
| Plate Thickness | 1/4" |
| Plate Type | B |
| Replacement Wheel | 200 NY2H |
| Standards | Icwm |
| Swivel Lock Type | No Lock Included |
| Tread Shape | Standard |
| Wheel Bearing Type | Precision Ball |
| Wheel Bearings | Precision Ball |
| Wheel Color | White |
| Wheel Core Material | Nylon |
| Wheel Diameter | 8" |
| Wheel Material | Nylon |
| Wheel Width | 2" |
| Wheel/tread Color | White |
| Wheel/tread Hardness | 80 Shore D |
| Wheel/tread Hardness Rating | Hard |
| Wheel/tread Material | Nylon |
| Height (cm) | 24.13 |
|---|---|
| Length (cm) | 19.81 |
| Width (cm) | 10.92 |
| HS Code | 8302200000 |
|---|---|
| Country Of Origin | GB |
| Weight (kg) | 3.141 |
| Style | Model | Mounting Plate Bolt Hole Pattern | Inside Bolt Hole Spacing | Outside Bolt Hole Spacing | Wheel Width | Wheel/tread Material | Load Rating | Mounting Height | Mounting Plate Size | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | TFSV 100 BN0S | A | 1 3/4" x 3" | 2 3/8" x 3 3/16" | 1 1/4" | Nylon | 330 lbs. | 5" | 3 1/8" x 4" | $20.06 | |
| A | TFSV 125 BN0S | A | 1 3/4" x 3" | 2 3/8" x 3 3/16" | 1 1/4" | Nylon | 330 lbs. | 6" | 3 1/8" x 4" | $22.26 | |
| B | TFK 125 NT0E | A | 3" x 3" | 2 5/8" x 3 5/8" | 1 3/4" | Nythane | 550 lbs. | 6 1/2" | 4" x 4 1/2" | $78.72 | |
| B | TFK 200 NT0E | A | 2 5/8" x 3" | 3" x 3 5/8" | 2" | Nythane | 880 lbs. | 9 1/2" | 4" x 4 1/2" | $184.06 | |
| C | TFH100PT1HT24 | A | 2 7/16" x 4 15/16" | 3 3/8" x 5 1/4" | 1 1/2" | Polyurethane | 480 lbs. | 6 1/8" | 5 3/4" x 6 9/16" | $112.45 | |
| D | TFH100CI1HT24 | A | 2 7/16" x 4 15/16" | 3 3/8" x 5 1/4" | 1 3/4" | Iron | 700 lbs. | 6 1/8" | 5 3/4" x 6 9/16" | $78.01 | |
| D | TFH125CI1HT24 | A | 2 7/16" x 4 15/16" | 3 3/8" x 5 1/4" | 1 3/4" | Iron | 1400 lbs. | 7 1/8" | 5 3/4" x 6 9/16" | $115.15 |
