REES 04965-000 Explosion-proof Switch, Slack Cable

Rees 04965-000 explosion-proof switch is a mechanical device ideal for a quick positive shut off of equipment during an emergency or normal operation in hazardous environments. This slack cable switch is particularly suitable for operation in conveyors, assembly lines & material handling systems for safe & quick stopping of equipment.

• Rees 04965-000 explosion-proof switch has a cable pull to actuate the switch and trip the flag arm in actuated position by locking the switch with a positive safety lock feature.
• The flag can be manually reset by returning the flag to its normal up position.
• It has a maximum recommended cable length of 100 feet per end with 10 feet of maximum interval support.
• This heavy-duty slack cable style switch can be mounted in any position and withstand harsh environments due to its rugged construction.
• It can be stretched in either or both directions without altering the internal system.

• Rees 02005-605 Turnbuckle: It is used to change the tension between two cables or ropes by rotating the frame, causing both eye bolts to screw in or out at the same time.
• Rees 02005-610 Steel Cable: It is used to set or reset the switch.
• Rees 02005-615 Thimble: This strain relief thimble is suitable for transition from a flexible cable to a hard connector or connecting point and assures reduction in breakage at the end.
• Rees 02005-620 Rope Clip: It is used to create a load-bearing eye at the end of a cable / wire rope or to make a lap splice between two cables.
• Rees 02005-625 Cable Clip Assembly: It is used to handle any size of a cable clip.
• Rees 02005-635 Eye Bolt Support: It serves as a point of connection for applications including rigging, anchoring, pulling, pushing or lifting. This unit features steel construction with zinc finish for durability.
• Rees 01004-050 Mounting Bracket: This mounting bracket is used to install the switch in desired location.

• ISO 9001:2015
• UL
• CSA
• NEMA
