| Item | Needle Valve |
|---|---|
| Bonnet Style | Integral |
| Connection Size - Side 1 | 1/4" |
| Connection Size - Side 2 | 1/4" |
| Connection Type | Compression x Compression |
| Fitting Style | Straight |
| Flow Rate | 0.43 GPM |
| For Media | Chemicals, Inert Gas, Oil |
| Handle Diameter | 1.38" |
| Handle Material | Nylon |
| Max. Flow | 0.43 GPM |
| Max. Pressure (cwp) | 5000 psi |
| Maximum Height | 3" |
|---|---|
| Media Temp. Range | -65°F to +450°F |
| Media Temperature Range | -65°F to +450°F |
| Overall Length | 2.3" |
| Pipe Size | 1/4" |
| Seal Material | PTFE |
| Stem Material | PCTFE |
| Stem Type | Regulating |
| Temp. Rating | -65°F to +450°F |
| Valve Body Style | Inline |
| Valve Series | V Series |
| Standards | ISA S75.02 |
| Height (cm) | 9.14 |
|---|---|
| Length (cm) | 5.87 |
| Width (cm) | 7.78 |
| HS Code | 8481803090 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.135 |
| Style | Model | Max. Flow | Pipe Size | Body Material | Max. Pressure | Stem Type | Temp. Rating | Flow Rate | Stem Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 2A-V2LR-SS | 0.12 GPM | - | Stainless Steel | 5000 psi | Blunt | -65°F to +450°F | 0.12 GPM | - | $477.66 | |
| A | 2A-V2LN-SS | 0.12 GPM | 1/8" | Stainless Steel | 5000 psi | Regulating | -65°F to +450°F | 0.12 GPM | PCTFE | $479.00 | |
| A | 4A-V4LR-SS | 0.43 GPM | - | - | - | V Stem | -65°F to +450°F | 0.43 GPM | PCTFE | $399.64 | |
| A | 4A-V4LK-SS | 0.45 GPM | - | - | 5000 psi | V Stem | -65°F to +450°F | 0.45 GPM | PCTFE | $430.79 | |
| A | 6A-V6LR-SS | 0.73 GPM | 3/8" | Stainless Steel | - | V Stem | -65°F to +450°F | 0.73 GPM | PTFE | $545.84 | |
| A | 6A-V6LN-SS | 0.55 GPM | 3/8" | Stainless Steel | - | Regulating | -65°F to +350°F | 0.55 GPM | PTFE | $544.44 | |
| A | 6A-V6LK-SS | 0.8 GPM | - | - | - | V Stem | -65°F to +450°F | 0.8 GPM | PCTFE | $521.89 |
