| Item | Four Outlet Receptacle |
|---|---|
| Afci | No |
| Amps | 15A |
| Application Environment | Commercial Environments |
| Color | Ivory |
| Connection Orientation | Straight |
| Connectivity | Screw Terminals |
| Contact Material | Brass |
| Cover Type | No Cover |
| Current Rating | 15A |
| Duty | Heavy Duty |
| Face Plate Height | 4.3" |
| Face Plate Width | 4.3" |
| Gfci | No |
| Grade | Federal Specification |
| Grounding | Grounded |
| Height | 4.3" |
| Housing Color | Ivory |
| Housing Material | Polycarbonate |
| Hp | 1/2 hp |
| Length | 4.3" |
| Material | Polycarbonate |
| Max. Hp | 1/2 hp |
| Maximum Operating Temperature | 167°F |
| Maximum Wire Size | 12 AWG |
| Minimum Operating Temperature | -40°F |
| Minimum Wire Size | 14 AWG |
| Mount Hole Center-to-center Height | 3.4" |
| Mount Hole Center-to-center Width | 3.4" |
|---|---|
| Mounting Type | Surface |
| Nema Enclosure Rating | 1 |
| Nema Rating | NEMA 5-15R |
| Nema Receptacle Configuration | NEMA 5-15R |
| Number Of Gangs | 2 |
| Number Of Outlets | 4 |
| Number Of Poles | 2 |
| Number Of Wires | 3 |
| Outlet Type | Quad |
| Overall Depth | 4.3" |
| Phase | 1 |
| Polarized | Yes |
| Power Indicator | No |
| Receptacle Type | Quad |
| Standards | Csa Certified C22.2 No. 42 File 285, Nema Wd-6, Ul 498 File E2186 |
| Surge Protection | No |
| Ul 94 Flammability Rating | V-2 |
| Voltage | 125V AC |
| Voltage Rating | 125V AC |
| Wattage | 1875 W |
| Weather Resistant | No |
| Width | 23/25" |
| Wire Connection Location | Back |
| Wire Connection Type | Screw Terminals |
| Wire Connection Types | Screw Terminals |
| Wire Size | #14 AWG to # 12 AWG |
| Wiring Method | Back |
| Height (cm) | 10.92 |
|---|---|
| Length (cm) | 10.92 |
| Width (cm) | 2.34 |
| HS Code | 8536698000 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.18 |
| Style | Model | Surge Protection | Current Rating | Housing Color | Wire Size | Nema Rating | Connectivity | Voltage | Amps | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | HBL415W | No | 15A | White | #14 AWG to # 12 AWG | NEMA 5-15R | Screw Terminals | 125V AC | 15A | $80.84 | |
| B | HBL420W | No | 20A | White | 12 AWG | NEMA 5-20R | Screw Terminals | 125V AC | 20A | $76.60 | |
| C | HBL415BK | No | 15A | Black | #14 AWG to # 12 AWG | NEMA 5-15R | Screw Terminals | 125V AC | 15A | $82.43 | |
| D | HBL415GY | No | 15A | Gray | #14 AWG to # 12 AWG | NEMA 5-15R | Screw Terminals | 125V AC | 15A | $77.66 | |
| E | HBL420BK | No | 20A | Black | 12 AWG | NEMA 5-20R | Screw Terminals | 125V AC | 20A | $71.41 | |
| F | HBL415 | No | 15A | Brown | #14 AWG to # 12 AWG | NEMA 5-15R | Screw Terminals | 125V AC | 15A | $75.00 | |
| G | HBL420 | No | 20A | Brown | 12 AWG | NEMA 5-20R | Screw Terminals | 125V AC | 20A | $83.00 |
