| Item | Speed Reducer |
|---|---|
| Center Distance | 3 1/4" |
| Center Distance Range | Above 3.25" |
| Gear Type | Worm |
| Housing Material | Cast Iron |
| Hp Range | 1 hp to 2 hp |
| Input Dia. | 7/8" |
| Input Style | Shaft |
| Keyway Size | 3/16" x 3/32" |
| Max. Input Hp | 1 17/20 hp |
| No. Of Gear Reductions | 1 |
| Output Dia. | 1 3/8" |
| Output Rpm | 29.2 RPM |
|---|---|
| Output Shaft | Shaft |
| Output Shaft Direction | Double |
| Output Shaft Orientation | LR |
| Output Torque Range | 2500 lbs.-in. to 5000 lbs.-in. |
| Overhung Load | 1100 |
| Product Line | Powercubex Worm Gear Drive |
| Product Type | Right Angle |
| Ratio | 60:1 |
| Service Factor | 1 |
| Style | A |
| Torque Rating | 2706 lbs.-in. |
| Height (cm) | 27.94 |
|---|---|
| Length (cm) | 30.48 |
| Width (cm) | 25.4 |
|---|---|
| Weight (kg) | 27 |
| Style | Model | Max. Input Hp | Frame Size | Gear Type | Overhung Load | Housing Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|
| A | 0230-14613 | 10 hp | - | Worm | 1100 | Cast Iron | $1,674.49 | |
| B | 0230-14616 | 5.57 hp | - | Worm | 1100 | Cast Iron | $1,674.49 | |
| C | 0230-14617 | 4.59 hp | - | Worm | 1100 | Cast Iron | $1,674.49 | |
| D | 0230-14631 | 3 14/25 hp | - | Worm | 1100 | Cast Iron | $1,674.49 | |
| E | 0230-14637 | 10 hp | - | Worm | - | Cast Iron | $2,207.97 | |
| F | 0230-14737 | 4.59 hp | - | Worm | - | Cast Iron | $2,207.97 | |
| G | 0230-14790 | 1 17/20 hp | 56C | Worm | 1100 | Cast Iron | $1,956.39 |
