| Item | Flange |
|---|---|
| Application | Non-Potable Water, Potable Water |
| Basic Fitting Shape | Flange |
| Body Material | CPVC |
| Bolt Circle Diameter | 11 3/4" |
| Bolt Hole Diameter | 13/16" |
| Class | Class 150 |
| Color | Gray |
| Connection Surface | Flat |
| Connection Type | Socket |
| Flange Outside Diameter | 13 1/2" |
| Flange Thickness | 1 1/4" |
| For Pipe Schedule | 80 |
| Green Certification Or Other Recognition | RoHS.png |
| Low Lead Certified Standard | Nsf61 |
|---|---|
| Max. Pressure | 150 psi |
| Max. Temp. | 176°F |
| Maximum Operating Pressure | 150 psi |
| No. Of Bolt Holes | 8 |
| Nominal Pipe Size | 8" |
| Number Of Holes | 8 |
| Outside Dia. | 13 1/2" |
| Overall Length | 1 1/2" |
| Pipe Fitting Material | CPVC |
| Schedule | 80 |
| Specific Fitting Shape | Blind Flange |
| Temp. Range | 176°F |
| Height (cm) | 34.92 |
|---|---|
| Length (cm) | 35.26 |
| Width (cm) | 23.65 |
| HS Code | 3917400000 |
|---|---|
| Weight (kg) | 2.7675 |
| Style | Model | Connection Type | Pipe Size | Specific Fitting Shape | Schedule | Color | Basic Fitting Shape | Temp. Range | Material | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 9854-080 | Socket | - | Van Stone Flange | 80 | Gray | Flange | 176°F | - | $348.61 | |
| B | 9853-005 | Socket | 1/2" | Blind Flange | 80 | Gray | Flange | 176°F | - | $21.91 | |
| B | 9853-007 | Socket | 3/4" | Blind Flange | 80 | Gray | Flange | 176°F | - | $24.99 | |
| A | 9854-040 | Socket | 4" | - | 80 | Gray | - | - | - | $70.61 | |
| A | 9854-060 | Socket | 6" | Van Stone Flange | 80 | Gray | Flange | 176°F | - | $120.31 | |
| B | 9856-005 | Spigot | 1/2" | Van Stone Flange | 80 | Gray | Flange | 176°F | - | $16.40 | |
| B | 9856-007 | Spigot | 3/4" | Van Stone Flange | 80 | Gray | Flange | 176°F | - | $18.29 |
