| Item | Proximity Sensor |
|---|---|
| Accuracy | Less Than 2% |
| Actuator Function | Unshielded |
| Connection | 4-pin M12 Connector |
| Contact Configuration | 2-wire DC, NC |
| Contact Rating | 100 mA at 30V DC |
| Enclosure Material | Brass |
| Input Voltage | 10-30V DC |
| Ip Rating | IP67, IP69K |
| Led Indicator | Output Status, Red |
| Length | 0.47" |
|---|---|
| Max. Operating Temp. | 158°F |
| Maximum Dc Current | 100 mA |
| Min. Operating Temp. | -13°F |
| Product Height | 2 17/25" |
| Product Name | Eaton E57 Inductive Proximity Sensor |
| Product Width | 0.47" |
| Protection Type | Short Circuit Protected |
| Sensor Type | Inductive Proximity |
| Warranty | 1 yr. |
| Height (cm) | 6.81 |
|---|---|
| Length (cm) | 1.19 |
| Width (cm) | 1.19 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 0.0281 |
| Style | Model | Ip Rating | Cable Length | Number Of Wires | Min. Operating Temp. | Max. Operating Temp. | Number Of Pins | Cable Material | Cable Type | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | E57-30PAS10-CY1 | IP67 | 42 ft. | - | -13°F | 158°F | - | PVC | - | $283.61 | |
| B | E57-12GE10-C1 | IP67, IP69K | 79.2 ft. | - | -13°F | 158°F | - | PVC | - | $233.36 | |
| B | E57-12GE10-C1DB | IP67, IP69K | - | - | -13°F | 158°F | - | - | - | $256.26 | |
| C | E57-12GE10-G | IP67, IP69K | 79.2 ft. | - | -13°F | 158°F | - | PVC | - | $217.74 | |
| C | E57-12GE10-G1 | IP67, IP69K | - | - | -13°F | 158°F | - | PVC | - | $233.36 | |
| C | E57-12GE10-G1DB | IP67, IP69K | - | - | -13°F | 158°F | - | - | - | $256.26 | |
| D | E57-12GS02-C1 | IP67, IP69K | 79.2 ft. | - | -13°F | 158°F | - | PVC | - | $171.80 |
