| Item | Hydraulic Motor |
|---|---|
| Continuous Torque | 3110 lbs.-in. |
| Flange Mount | 2 Bolt, 3.25" Pilot |
| Height | 5.17" |
| Max. Oil Temp. | 180°F |
| Min. Oil Viscosity | 100 SUS |
| Mounting Plate Width | 5.17" |
| Port Location | Side |
|---|---|
| Port Size | 7/8"-14 O-Ring |
| Port Type | Side |
| Series | H Series |
| Shaft Dia. | 1" |
| Shaft Type | Keyed |
| Width | 5.17" |
| Height (cm) | 11.43 |
|---|---|
| Length (cm) | 26.67 |
| Width (cm) | 13.21 |
| HS Code | 8412298015 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 6.48 |
| Style | Model | Continuous Torque | Port Size | Pressure Rating | Displacement | Max. Rpm | Height | Mounting Plate Width | Shaft Dia. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 101-1037 | 2343 lbs.-in. | 7/8"-14 O-Ring | - | 11.3 cu. in./rev. | - | 5.17" | 5.17" | 1" | $915.26 | |
| A | 101-1038 | 2669 lbs.-in. | 7/8"-14 O-Ring | - | 14.1 cu. in./rev. | 243 RPM | 5.17" | 5.17" | 1" | $906.05 | |
| B | 101-1013 | 2343 lbs.-in. | 7/8"-14 O-Ring | - | 11.3 cu. in./rev. | - | 3.31" | 3.31" | 1" | $773.09 | |
| B | 101-1014 | 2669 lbs.-in. | 7/8"-14 O-Ring | - | - | 243 RPM | 3.31" | 3.31" | 1" | $890.10 | |
| B | 101-1015 | 3110 lbs.-in. | 7/8"-14 O-Ring | - | 17.9 cu. in./rev. | - | 3.31" | 3.31" | 1" | $1,000.36 | |
| B | 101-1001 | 650 lbs.-in. | 1/2" | 1800 psi | 2.8 cu. in./rev. | 969 RPM | 3.31" | 3.31" | 1" | $723.83 | |
| B | 101-1002 | 1044 lbs.-in. | 1/2" | 1800 psi | 4.5 cu. in./rev. | 760 RPM | 3.31" | 3.31" | 1" | $789.81 |
