| Item | General Purpose Motor |
|---|---|
| Ambient Temp. | 40°C |
| Amps @ Volts | 11.8A @ 115V, 5.9A @ 230V |
| Base Type | Rigid Base |
| Duty Cycle | Continuous |
| Frame | 56C |
| Frame Material | Steel |
| Frequency | 60 Hz |
| Full Load Amps | 11.8A @ 115V, 5.9A @ 230V |
| Grease Type | Polyrex EM |
| Hp | 1 1/2 hp |
| Insulation Class | Class B |
| Motor Enclosure Design | Open Dripproof |
| Motor Type | Capacitor Start/Run |
|---|---|
| Mounting Type | C Face, Foot Mounted |
| Nameplate Rpm | 3480 RPM |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Overall Length | 12.94" |
| Phase | 1 |
| Power Factor | 99 |
| Service Factor | 1.15 |
| Start Type | Direct On Line |
| Synchronous Speed | 3600 RPM |
| Voltage | 115/230V AC |
| Height (cm) | 13.15 |
|---|---|
| Length (cm) | 32.87 |
| Width (cm) | 13.15 |
| Country Of Origin | US |
|---|---|
| Weight (kg) | 23.4 |
